Klauke EK12030L EK12030L Squeezer Crimp connectors 10 up to 400 mm² incl. exchangeable crimp insets
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Press-shape: Universal (changeable inserts)
- Execution/activation: Battery-hydraulic
- Inserts can be replaced: Yes
- With automatic reverse: Yes
- Product type
Squeezer
- Manufacturer part #
EK12030L
- Range of uses
Crimp connectors
- Crimp area
10 up to 400 mm²
- Crimp area (min.)
10 mm²
- Crimp area (max.)
400 mm²
- Suitable for
Klauke
- Features
incl. exchangeable crimp insets
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3430332 Klauke EK12030L EK12030L Squeezer Crimp connectors 10 up to 400 mm² incl. exchangeable crimp insets
User & Safety Instructions
User & Safety Instructions 3430332 Klauke EK12030L EK12030L Squeezer Crimp connectors 10 up to 400 mm² incl. exchangeable crimp insets
Description
Open C-shape press head, rotatable, for interchangeable 13 series inserts, wide press, integrated pressure measurement with optical and acoustic signals in the event of a fault, evaluation function via optical interface and USB adapter, with LED for illumination of the work area, motor quick stop for high user safety, automatic return after complete pressing
