Klauke EKSD50ML EKSD50ML Universal Cable stripper tool set 6 up to 35 mm² 12.5 mm (max)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Stripping tool set Klauke micro
- One-button operating concept for controlling all tool functions
- Automatic rewind after completion of operation
- Manual reverse if required
- Strip length adjustable up to 28 mm via cable stop
- Strip insulation and cut with one insert
- Suitable for left and right handed use
- Interchangeable inserts
- High-performance 10.8V Li-ion rechargeable battery - with charging status indicator
- LED for work-room lighting
- Maintenance display by means of LED
- Project-related logging with Klauke LINK® APP software package
Technical specifications
- Stripping length: Max. 28 mm
- Product type
Cable stripper tool set
- Suitable for
PVC-coated round cable
- Operating range (diameter)
12.5 mm (max)
- Operating range (diameter) (max.)
12.5 mm
- Working area (cross section)
6 up to 35 mm²
- Working area cross section (min.)
6 mm²
- Operating range (cross section) (max.)
35 mm²
- Range of use
Universal
- Length stop range
28 mm (max)
- Length stop (max.)
28 mm
- Material
Plastic
- Weight
0.96 kg
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3429943 Klauke EKSD50ML EKSD50ML Universal Cable stripper tool set 6 up to 35 mm² 12.5 mm (max)
User & Safety Instructions
User & Safety Instructions 3429943 Klauke EKSD50ML EKSD50ML Universal Cable stripper tool set 6 up to 35 mm² 12.5 mm (max)
Description
The Klauke micro with intuitive PowerSense function simplifies the stripping of all common types of conductors with the comfort of an electromechanical tool. Suitable for all common insulation types (PVC, halogen-free, rubber, silicone, XLPE) up to a maximum outer diameter of 11.5 mm. Klauke micro stripping tool set is supplied with stripping inserts from 10 to 35 mm² including cable stop and grease.
This text is machine translated.
This text is machine translated.
Features
- A tool for all common types of insulation
- Quick and easy replacement of inserts
- Fast, fatigue-free stripping and cutting
- Excellent stripping results with minimum application of force
Scope of delivery
- Electromechanical stripping tool 6 - 35 mm² (EKSD50ML)
- Stripping insert 10 mm² (SD5010)
- Stripping insert 16 mm² (SD5016)
- Stripping insert 25 mm² (SD5025)
- Stripping insert 35 mm² (SD5035)
- Cable stop (SD50CS)
- Charger for 10.8 V Li-ion rechargeable batteries, 230V (LGML1)
- Battery 10.8 V / 2.5 Ah, Li-Ion (27 Wh) (RAML1225)
