Klauke HK12030 HK12030 Squeezer universal 16 up to 400 mm² incl. exchangeable crimp insets
EAN:
Part number:
Item no:
Technical specifications
- Press-shape: Universal (changeable inserts)
- Execution/actuation: Hand-hydraulic
- Inserts can be replaced: Yes
- With automatic reverse: Yes
- Number of inserts supplied: 1
- Product type
Squeezer
- Manufacturer part #
HK12030
- Range of uses
universal
- Crimp area
16 up to 400 mm²
- Crimp area (min.)
16 mm²
- Crimp area (max.)
400 mm²
- Length
510 mm
- Material
Aluminium
- Features
incl. exchangeable crimp insets
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3430335 Klauke HK12030 HK12030 Squeezer universal 16 up to 400 mm² incl. exchangeable crimp insets
Description
Up to 60% less pressing due to wide crimping as compared to 6 t tools. For replaceable inserts of the 13 series, wide crimping. Open C-shape press head, rotatable. Low weight through high-quality aluminum casing. 2-stage hydraulics with fast forward and power stroke. Automatic rewind after complete crimping Manual reverse if required. Environmentally friendly hydraulic oil, rapidly biodegradable. Steel sheet box with space for 15 pair of crimp inserts (MK12042).
