Name: Klingspor 331023 DS 600 S diamond grinding disc, 115 x 7.2 x 22.23 mm 16 segments 7.2 x 5.5 mm, special geometry Diamete
Brand: Klingspor
SKU: 3530180
Availability: BackOrder

A circular metal grinding disc with evenly spaced eight segmented sections, used for abrasive cutting or surface grinding.

Image similar

Datasheet (PDF)

Dispatches on Thu 22 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 87.99 / piece)

€ 87.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

DS 600 S diamond grinding disc, 115 x 7.2 x 22.23 mm 16 segments 7.2 x 5.5 mm, special geometry

Excellent dust removal thanks to the special shape of the opening (fan-shaped)
Low weight through light steel plate
Stable performance and low-vibration operation
M14 adapter available, see DZ 114

Technical specifications

Main field of application: Concrete, shamottes, natural stone, masonry, bricks
Usage: Angle grinder
Aggressivity: High
Design: Soldered
Segmentation: Standard
Service life: Very high
Top speed 80 m/s.
Maximum speed 13300 rpm
Machine type: Angle grinder
Edge design: Special geometry
Hole diameter 22.23 mm
Number of segments: 16 pcs
Segment width 7.2 mm
Segment height 5.5 mm

Product type: Sanding disc mount

(Ø): 115 mm

Content: 1 pc(s)

Features: Diamond

Material suitability: Concrete
Natural stone
Masonry
Roof tile
Brick
Solid brick
Cored brick

Bore Ø: 22.23 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3530180 Klingspor 331023 DS 600 S diamond grinding disc, 115 x 7.2 x 22.23 mm 16 segments 7.2 x 5.5 mm, special geometry Diamete

User & Safety Instructions

User & Safety Instructions 3530180 Klingspor 331023 DS 600 S diamond grinding disc, 115 x 7.2 x 22.23 mm 16 segments 7.2 x 5.5 mm, special geometry Diamete

Information

Information 3530180 Klingspor 331023 DS 600 S diamond grinding disc, 115 x 7.2 x 22.23 mm 16 segments 7.2 x 5.5 mm, special geometry Diamete

Description

DS 600 S Supra with special geometry is Ideal for the dust-free grinding of concrete, chimney, natural stone and brick. The light professional grinding disc for daily use offers excellent dust removal and very long service life.
