Klingspor 366500 NCO 700DB compact discs 9 SF hard, 152.4 x 25.4 x 25.4 mm fine silicon carbide 152.4 mm 2 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 2 pc(s))
Total (€ 46.22 / piece)
€ 92.43
plus VAT.
14-day return policy included
Highlights & Details
NCO 700DB compact discs 9 SF hard, 152.4 x 25.4 x 25.4 mm fine silicon carbide
- Open structure, no addition
- Excellent satin finish with very low depth of crowing
- Good durability, constant, reproducible finish
- Removal of medium (7SF) to strong burrs (9SF) without secondary burr formation
- Low-cost design with excellent value for money for applications with lower speeds
Technical specifications
- Main application areas: Stainless steel, titanium/alloys, steel, high-alloy steels, non-ferrous metals, Aluminium
- Possible application area: Plastic
- Usage: Grinding block
- Binding: Synthetic resin
- Grain type SiC
- Maximum speed [m/s]: 47 m/s.
- Maximum speed per minute: 6000 rpm
- Hardness: 9 SF
- Fleece fineness: Fine
- Fleece grain type: Silicon carbide
- Hole diameter 25.4 mm
- Product type
Abrasive disc
- (Ø)
152.4 mm
- Length
152.4 mm
- Content
2 pc(s)
- Width
25.4 mm
Documents & Downloads
Datasheet
Datasheet 3529721 Klingspor 366500 NCO 700DB compact discs 9 SF hard, 152.4 x 25.4 x 25.4 mm fine silicon carbide 152.4 mm 2 pc(s)
User & Safety Instructions
User & Safety Instructions 3529721 Klingspor 366500 NCO 700DB compact discs 9 SF hard, 152.4 x 25.4 x 25.4 mm fine silicon carbide 152.4 mm 2 pc(s)
Information
Information 3529721 Klingspor 366500 NCO 700DB compact discs 9 SF hard, 152.4 x 25.4 x 25.4 mm fine silicon carbide 152.4 mm 2 pc(s)
Description
Wandled compact fleece wheels with good tool life for removing light to medium burrs, rounding of sharp workpiece edges, smoothing of grinding patterns, removing surface defects and machining traces. Low adding thanks to open structure. Inexpensive design with excellent price/performance ratio. Create an excellent satin cross-sectional image with very low depth of roughage.
