Knipex 62 12 120 Electrical & precision engineering Angle cutter flush-cutting 120 mm
EAN:
Part number:
Item no:
Number
Total (€ 30.24 / piece)
€ 30.24
plus VAT.
14-day return policy included
Highlights & Details
Knipex 62 12 120 Electrical & precision engineering Angle cutter flush-cutting 120 mm
- With cutting edges for soft and medium hard wire
- Without bevel, for flush cutting
- Cutting edges additionally induction hardened, cutting edge hardness approx. 58 HRC
- Low-friction double spring for gentle and even opening
- Sturdy, zero backlash box joint
- The polish together with a fine film of oil offer effective rust protection - no circuit faults caused by peeling chrome from plated tools
- High-grade special tool steel, forged, oil-hardened
Technical specifications
- Head dimensions A 11.00 mm
- B 10.00 mm
- D 7.50 mm
- C 17.00 mm
- Angle 15 °
- Product type
Angle cutter
- Manufacturer part #
62 12 120
- Range of use
Electrical & precision engineering
- Length
120 mm
- Material
Tool steel
- Material properties
tempered
polishing
- Edge hardness
58 HRC
- Wire hardness (max.) soft wire
1 mm
- Wire hardness (max.) medium wire
0.7 mm
- DIN standard
DIN ISO 9654
- Weight
93 g
- Features
flush-cutting
- Type
Electronics diagonal cutter
- Type
62 12 120
- Standards
DIN ISO 9654
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 822227 Knipex 62 12 120 Electrical & precision engineering Angle cutter flush-cutting 120 mm
Description
With cutting edges for soft and medium wires. Without facet, for even cutting. Cutting edges additionally induction hardened, cutting edge hardness approx. 58 HRC. Low-friction dual spring for gentle and even opening Precision box joint hinge The mirror polishing offers together with a fine oil film a excellent protection against rust - no interference in the circuits through peeling chromium parts Cutting head: special tool steel in special quality, forged, oil-hardened
This text is machine translated.
This text is machine translated.
Features
- Together with a fine layer of oil, the mirror polishing provides excellent protection against rust – no flaking chrome parts causing faults in the circuit
- Blades for soft and medium-hard wire
- Without facet, for even cutting.
- Cutting hardness approx. 58 HRC
- Friction-less dual spring for a soft and uniform opening
- Inserted precision joint
