Buy Knipex 74 12 160 Workshop Kraft side cutter non-flush type 160 mm

Side cutters cut black and copper-coloured cables. 'Knipex' marking visible on the pliers. Essential tool for electricians.

A red and blue KNIPEX side cutting pliers, model 74 12 160, suitable for clippings up to 2.0 mm.

The pliers are holding a metal spring. They have red and black handles and are marked with 'KNIPEX'.

1/5

Fast track dispatch on Thu, 1 Oct

4 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 23.52 / piece)

€ 23.52

plus VAT.

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

High leverage diagonal cutters

For heavy-duty, continuous use
High cutting power with low application of force through optimum matching of cutting angle and transmission ratio
Precision cutting edges additionally induction hardened, cutting edge hardness approx. 64 HRC) for all sorts of wire, including piano wire
Chrome-vanadium high speed steel, forged, oil-hardened multi-level

Technical specifications

Product type: Kraft side cutter

Manufacturer part #: 74 12 160

Range of use: Workshop

Length: 160 mm

Material: Chromium-vanadium steel

Material properties: tempered
polishing

Edge hardness: 64 HRC

Wire hardness (max.) medium wire: 3.4 mm

Wire hardness (max.) hard wire: 2.5 mm

Wire hardness piano wire (max.): 2.0 mm

DIN standard: DIN ISO 5749

Width: 53 mm

Height: 20 mm

Weight: 209 g

Features: non-flush type

Type: Power side-cutter

Type: 74 12 160

Standards: DIN ISO 5749

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 822288 Knipex 74 12 160 Workshop Kraft side cutter non-flush type 160 mm

Description

With forged joint axle for very tough, continuous use Ideal for all sorts of wire, including piano wire High cutting power with low application of force through optimum matching of cutting angle and transmission ratio Precision cutting edges additionally induction hardened, cutting edge hardness approx. 64 HRC Chrome-vanadium high speed steel, forged, oil-hardened multi-level

This text is machine translated.

Features

Precision cutting edges additionally induction hardened, cutting edge hardness approx. 64 HRC
High cutting performance with minimum effort thanks to optimum co-ordination of the cutting edge angle and transmission ratio
Ideal for all sorts of wire, including piano wire
With forged joint axle for very tough, continuous use
