Knipex 97 49 16 Crimp inset Insulated cable lugs, Insulated connectors 10 up to 16 mm² Suitable for brand (pliers) Knipe
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 53.77 / piece)
€ 56.29
€ 53.77
plus VAT.
Highlights & Details
Crimp profiles
Technical specifications
- Product type
Crimp inset
- Manufacturer part #
97 49 16
- Range of uses
Insulated cable lugs
Insulated connectors
- Crimp area AWG
5 up to 7 awg
- Crimp area (min.)
10 mm²
- Crimp area (max.)
16 mm²
- Crimp area AWG (min.)
7 awg
- Crimp area AWG (max.)
5 awg
- Length
80 mm
- Width
50 mm
- Weight
46 g
- Suitable for
Knipex
- Suited for model
97 43 200
97 43 E
97 43 E AUS
97 43 E UK
97 43 E US
- Crimp area
10 up to 16 mm²
- Range of uses
Insulated cable lugs + Connectors
- Type
97 49 16
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 823958 Knipex 97 49 16 Crimp inset Insulated cable lugs, Insulated connectors 10 up to 16 mm² Suitable for brand (pliers) Knipe
User & Safety Instructions
User & Safety Instructions 823958 Knipex 97 49 16 Crimp inset Insulated cable lugs, Insulated connectors 10 up to 16 mm² Suitable for brand (pliers) Knipe
Description
Application: insulated cable shoes + plug connector 10.0 - 16.0 mm²
This text is machine translated.
This text is machine translated.
Hints
Only into use with the system KNIPEX Pliers code 82 39 31 Use!
