KRAH ZDFL 21X120B 10% 220R High power resistor 220 Ω Solder tags 65 W 10 % 1 pc(s)
EAN:
Part number:
Item no:
Product type
High power resistor
Resistance
220 Ω
Power rating
65 W
Content
1 pc(s)
Type
Solder tags
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.88
3
4% = € 1.17
€ 25.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.88 / piece)
€ 26.88
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Wire resistance, 220 Ω, 65 W, ±10 %
Our service for you
Technical specifications
- Product type
High power resistor
- Type
Solder tags
- Resistance
220 Ω
- Power rating
65 W
- Tolerance ±
10 %
- Length
120 mm
- (Ø)
21 mm
- Max. temperature
350 °C
- Threshold voltage
900 V
- Content
1 pc(s)
- Dim
(Ø x L) 21 mm x 120 mm
- RoHS-compliant
Yes
- Type
ZDFL 21X120B 10% 220R
Documents & Downloads
Datasheet
Datasheet 3023853 KRAH ZDFL 21X120B 10% 220R High power resistor 220 Ω Solder tags 65 W 10 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3023853 KRAH ZDFL 21X120B 10% 220R High power resistor 220 Ω Solder tags 65 W 10 % 1 pc(s)
Description
Cemented high-load-wire wound resistors 65 Watt Tolerance 10 % Typ KRAH ZDFL.
