KS Tools 1503130 Belt pulley puller Clamping range (details) 90 mm No. of hooks 3
EAN:
Part number:
Item no:
Number
Total (€ 31.92 / piece)
€
Technical specifications
- Pull hook width G: 12 mm
- Pull hook total depth F: 11 mm
- Pull hook height D 10 mm
- Pull hook tip depth E: 6 mm
- Number of pull hooks: With 3 pull-off hooks
- Hexagon drive in mm: 24 mm
- Torque max Nm:35 Nm
- Weight 900 g
- Material1: Special tool steel
- max. Pressure force t: 2.5
- Quick adjustment: No. nein
- Clamping depth B in mm 30 mm
- Span A in mm 90 mm
- Spindle size mm: M16x1.5 x 75
- Clamping range
90 mm
- Dim
- Weight
900 g
- Content
1 pc(s)
- Span depth (max.)
30 mm
- Hooks
3
- Product type
Belt pulley puller
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2694030 KS Tools 1503130 Belt pulley puller Clamping range (details) 90 mm No. of hooks 3
Description
For removing belt pulleys without damagingCan be used universally for several diameters and different division of holesCompact design means no space requiredSuitable for working on the installed and removed motorSpecial tool steel
This text is machine translated.
This text is machine translated.
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
