LAPP 11285000 Pin inset EPIC® H-DD 24 Total number of pins 24 + PE 1 pc(s)
EAN:
Part number:
Item no:
Product type
Pin inset
Series
EPIC® H-DD 24
Connection
Crimp
Features
for machined contacts
Number of pins
24
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 13.44
3
6% = € 0.74
€ 12.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 13.44 / piece)
€ 18.48
-27 %
€ 13.44
plus VAT.
Only 5 Piece(s) available
Highlights & Details
EPIC® plug insert H-DD 24 series
Our service for you
Technical specifications
- Product type
Pin inset
- Series
EPIC® H-DD 24
- Features
for machined contacts
- Connection
Crimp
- Number of pins
24
- Total no. of pins
24 + PE
- Core cross section (min.)
0.14 mm²
- Core cross section (max.)
2.5 mm²
- Rated surge voltage
2.5 kV
- Rated voltage
IEC: 250 V
UL: 600 V
CSA: 600 V
- Test current
IEC: 10 A
UL: 8,5 A
CSA: 10 A
- Content
1 pc(s)
- Leading contact (PE)
Yes
- Type
Pin insert
- Type
EPIC® panel-mount base H-DD 24 SCM
- Pins
24 + PE
- Connection
-
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 747388 LAPP 11285000 Pin inset EPIC® H-DD 24 Total number of pins 24 + PE 1 pc(s)
User & Safety Instructions
User & Safety Instructions 747388 LAPP 11285000 Pin inset EPIC® H-DD 24 Total number of pins 24 + PE 1 pc(s)
Information
Information 747388 LAPP 11285000 Pin inset EPIC® H-DD 24 Total number of pins 24 + PE 1 pc(s)
Description
The H-DD series with machined contacts is designed for a high number of pins in very tight spaces. This allows for smaller housing types to be chosen.
