LAPP 1234006/100 Wire ÖLFLEX® HEAT 125 SC 1 x 1 mm² 100 m
EAN:
Part number:
Item no:
Product type
Wire
No. of leads
1 x
Cross section (each core)
1 mm²
Cable type
ÖLFLEX® HEAT 125 SC
Outside Ø
2.5 mm
Datasheet (PDF)
Technical specifications
- Product type
Wire
- No. of leads
1 x
- Content
100 m
- Cross section (each core)
1 mm²
- Insulation material
Polyolefin
- Cable type
ÖLFLEX® HEAT 125 SC
- Outside Ø
2.5 mm
- Nominal voltage
500 V
- Packaged
Yes
- Halogen-free
Yes
- Manufacturer part #
1234006/100
- Sold per metre
No
- Nominal voltage U0
300 V
- Cross section
1 x 1 mm²
- Type
ÖLFLEX® HEAT 125 SC 1X1 GN
Documents & Downloads
Datasheet
Datasheet 3388518 LAPP 1234006/100 Wire ÖLFLEX® HEAT 125 SC 1 x 1 mm² 100 m
User & Safety Instructions
User & Safety Instructions 3388518 LAPP 1234006/100 Wire ÖLFLEX® HEAT 125 SC 1 x 1 mm² 100 m
Description
ÖLFLEX ® HEAT 125 SC 1X1 GN single wire; 1X1; green; U0/U: 300/500 V; radiation cross-linked polymer compound; -55°C - 125°C; fixed wiring
