Buy LAPP 1238000/500 Strand ÖLFLEX® HEAT 125 SC 1 x 6 mm² Green, Yellow 500 m

Black cable labelled 'Lapp Kabel Stuttgart Oelflex Heat XFS SC 1x12 0.6/1kV PAIR'.

Image similar

Product type

Strand

No. of leads

1 x

Cross section (each core)

6 mm²

Cable type

ÖLFLEX® HEAT 125 SC

Outside Ø

4.80 mm

Datasheet (PDF)

Dispatches on Thu, 17 Sep

43 Set(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Packaging units

Number

Set(s)

Total (1 m = € 2.28)

€ 1,142.02

plus VAT.

Report legal concerns

Highlights & Details

Oilflex ® HEAT 125 SC

Technical specifications

Product type: Strand

No. of leads: 1 x

Content: 500 m

Cross section (each core): 6 mm²

Insulation material: Polyolefin

Cable features: Flame-retardant
Halogen-free
Oil-resistant
Flexible

Cable type: ÖLFLEX® HEAT 125 SC

Outside Ø: 4.80 mm

Nominal voltage: 750 V

Packaged: Yes

Halogen-free: Yes

Manufacturer part #: 1238000/500

Factory colour: Green
Yellow

Core layout: Stranded tinned copper stranded conductor according to IEC 60228 and VDE 0295, Class 5

Sold per metre: No

Nominal voltage U0: 450 V

Test voltage: 4 kV

Cross section: 1 x 6 mm²

Max. temperature range (flexible installation): +125 °C

Min. temperature range (flexible installation): -55 °C

Max. temperature range (fixed installation): +125 °C

Min. temperature range (fixed installation): -55 °C

Type: ÖLFLEX HEAT 125 SC 1X6 GNYE

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1335717 LAPP 1238000/500 Strand ÖLFLEX® HEAT 125 SC 1 x 6 mm² Green, Yellow 500 m

User & Safety Instructions

User & Safety Instructions 1335717 LAPP 1238000/500 Strand ÖLFLEX® HEAT 125 SC 1 x 6 mm² Green, Yellow 500 m

Description

Oilflex ® HEAT 125 SC single wires are heat-resistant, halogen-free single conductor cables with networked polyolefin copolymer insulation with very good mechanical properties. The line is typically used for internal
Wiring of lights, heating devices, electric machines (thermal class B), switching device combinations as well as equipment and apparatus construction.

This text is machine translated.
