LAPP 12474/100 Connection cable ÖLFLEX® 540 P 3 x 4 mm² + 3 x 4 mm² Yellow 100 m
EAN:
Part number:
Item no:
Product type
Connection cable
Cable type
ÖLFLEX® 540 P
No. of leads
3 x
Cross section (each core)
4 mm²
No. of leads (part 2)
3 x
Datasheet (PDF)
Total (1 m = € 9.87)
€ 987.39
plus VAT.
14-day return policy included
Highlights & Details
ÖLFLEX® 540 P TPE/PUR connection cable
- Halogen-free
- flame-adversely
Technical specifications
- Product type
Connection cable
- Cable type
ÖLFLEX® 540 P
- No. of leads
3 x
- Cross section (each core)
4 mm²
- No. of leads (part 2)
3 x
- Cross section (each core) (part 2)
4 mm²
- Cross section
3 x 4 mm² + 3 x 4 mm²
- Cable features
Halogen-free
Oil-resistant
Cold-resistant
PUR coating
- Factory colour
Yellow
- Outside Ø
12.3 mm
- Content
100 m
- Core layout
Finely stranded according to VDE 0293, Class 5/IEC 228 Class 55
- Packaged
Yes
- Sold per metre
No
- Halogen-free
Yes
- Shielded
No
- Manufacturer part #
12474/100
- Insulation material
Polyurethane
- Min. temperature range (flexible installation)
-40 °C
- Max. temperature range (flexible installation)
+90 °C
- Min. temperature range (fixed installation)
-50 °C
- Max. temperature range (fixed installation)
+90 °C
- Certification marks
VDE REGISTRATION NUMBER 6584
- Wire ID code
Wire identification colour coded according to VDE 0293 or VDE 0293-308, (7-core with printed numbering)
- Type
ÖLFLEX 540 P 3G4
- Max. length sold by the metre
100 m
- Material (details)
Hydrolysis resistant one PUR-MIXTURE
- Type
ÖLFLEX® 540 P 2X0.75
- Bend radius
Minimum bend radius for flexible application: 10 x external dia. · when fixed: 4 x external dia.
- Temperature range
MOVED: -40 - +90 °C, FIXED: -50 - +90 °C
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1336217 LAPP 12474/100 Connection cable ÖLFLEX® 540 P 3 x 4 mm² + 3 x 4 mm² Yellow 100 m
User & Safety Instructions
User & Safety Instructions 1336217 LAPP 12474/100 Connection cable ÖLFLEX® 540 P 3 x 4 mm² + 3 x 4 mm² Yellow 100 m
Description
The universal PUR service cable for Europe with VDE registration is ideal for use on construction sites, in agriculture and for camping. This cable can be used in wet, cold, dry, or heat conditions, indoors or outdoors, as an extension cable or machine connection cable.
