Buy LAPP 1249705/100 Heat-resistant cable ÖLFLEX® HEAT 180 SiF A 1 x 1.50 mm² Yellow 100 m

Black cable with the marking 'LAPP KABEL STUTTGART ÖLFLEX HEAT 180 SiF A CE'. Cable specifications.

Image similar

Cable type

ÖLFLEX® HEAT 180 SiF A

Cross section (each core)

1.50 mm²

Outside Ø

3.15 mm

No. of leads

1 x

Product type

Heat-resistant cable

Datasheet (PDF)

15 Set(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Set(s)

Total (1 m = € 0.71)

€

Report legal concerns

Highlights & Details

Oilflex ® HEAT 180 SIF A

Technical specifications

Nominal voltage: 1000 V

Cable type: ÖLFLEX® HEAT 180 SiF A

Content: 100 m

Cross section: 1 x 1.50 mm²

Factory colour: Yellow

Cross section (each core): 1.50 mm²

Halogen-free: Yes

Insulation material: Silicone

Cable features: Halogen-free
Heat-resistant
Cold-resistant

Manufacturer part #: 1249705/100

Type: ÖLFLEX HEAT 180 SiF A 1x1,5 YE

Outside Ø: 3.15 mm

Nominal voltage U0: 600 V

Max. temperature range (fixed installation): -50 °C

Min. temperature range (fixed installation): -50 °C

Max. temperature range (flexible installation): -50 °C

Min. temperature range (flexible installation): -50 °C

No. of leads: 1 x

Packaged: Yes

Core layout: Finely stranded according to VDE 0295, Class 5/IEC 60228, tin-plated

Test voltage: 3000 V

Sold per metre: No

Product type: Heat-resistant cable

Documents & Downloads

Datasheet

Datasheet 1500962 LAPP 1249705/100 Heat-resistant cable ÖLFLEX® HEAT 180 SiF A 1 x 1.50 mm² Yellow 100 m

LAPP 1249705/100 Heat-resistant cable ÖLFLEX® HEAT 180 SiF A 1 x 1.50 mm² Yellow 100 m
