LAPP 4726073K Strand H07Z-K 1 x 4 mm² Violet 600 m
EAN:
Part number:
Item no:
Product type
Strand
No. of leads
1 x
Cross section (each core)
4 mm²
Cable type
H07Z-K
Outside Ø
4.90 mm
8 Set(s)
Sales and shipping:
Number
Total (1 m = € 1.13)
€
Only 8 Set(s) available
Highlights & Details
H07Z-K 90°C single wire
- Flame-resistant according to IEC 60332-2-2
Technical specifications
- Product type
Strand
- No. of leads
1 x
- Content
600 m
- Cross section (each core)
4 mm²
- Cable features
Flame-retardant
Halogen-free
Harmonised
Flexible
- Cable type
H07Z-K
- Outside Ø
4.90 mm
- Nominal voltage
750 V
- Packaged
Yes
- Halogen-free
Yes
- Manufacturer part #
4726073K
- Factory colour
Violet
- Core layout
Fine strand according to VDE 0295, Class 5 / IEC 60228 Cl. 5
- Sold per metre
No
- Nominal voltage U0
450 V
- Certification marks
According to VDE 0282 Part 9 / HD 22.9 S1
- Test voltage
2500 V
- Cross section
1 x 4 mm²
- RoHS-compliant
- Max. temperature range (flexible installation)
+90 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+90 °C
- Min. temperature range (fixed installation)
-15 °C
- Type
H07Z-K 90°C EMBOSS 1X4 VT
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1334446 LAPP 4726073K Strand H07Z-K 1 x 4 mm² Violet 600 m
Description
Halogen-free single conductor with improved properties in the event of fire. They are intended for use in dry rooms, for cabling lighting, equipment, switchboard and distribution panels, in buildings containing large numbers of people or material assets, as well as in transportation systems.
