LAPP 53015360 Cable gland PG29 Polyamide Black (RAL 9005) 25 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
PG29
Material
Polyamide
Clamp Ø
11 mm
Terminal Ø (max.)
20 mm
Datasheet (PDF)
Technical specifications
- Product type
Cable gland
- Factory colour
Black (RAL 9005)
- External thread
PG29
- Material
Polyamide
- Clamp Ø
11 mm
- Terminal Ø (max.)
20 mm
- Thread length
11 mm
- Min. temperature
-20 °C
- Max. temperature
+80 °C
IP68
- Spanner size
42 mm
- Halogen-free
No
- Content
25 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
53015360
- Type
SKINTOP® STR PG 29
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1044092 LAPP 53015360 Cable gland PG29 Polyamide Black (RAL 9005) 25 pc(s)
User & Safety Instructions
User & Safety Instructions 1044092 LAPP 53015360 Cable gland PG29 Polyamide Black (RAL 9005) 25 pc(s)
Description
Enhanced oil resistance for higher reliability. Permanent vibration protection. Optimum strain relief. Large, variable clamping ranges. Accessories diversity (e.g. Multiple sealing inserts).
