LAPP 61749510 Shielding connecting plug 6.63 mm² Not insulated Red 100 pc(s)
EAN:
Part number:
Item no:
Product type
Shielding connecting plug
Cross section per core
6.63 mm²
Insulation type
Not insulated
Content
100 pc(s)
Factory colour
Red
Datasheet (PDF)
Highlights & Details
SHIELD-KON ® Shield connector
- Red
Technical specifications
- Internal diameter. 2.76 mm.
- Product type
Shielding connecting plug
- Cross section per core
6.63 mm²
- Insulation type
Not insulated
- Factory colour
Red
- Content
100 pc(s)
- Contact material
Galvanised
- Manufacturer part #
61749510
- Cross-section x Length
6.63 mm²
- RoHS-compliant
Yes
- Features
no insulation
- Type
GSB 109
- Type
Inner sleeve
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1041851 LAPP 61749510 Shielding connecting plug 6.63 mm² Not insulated Red 100 pc(s)
User & Safety Instructions
User & Safety Instructions 1041851 LAPP 61749510 Shielding connecting plug 6.63 mm² Not insulated Red 100 pc(s)
Description
SHIELD-KON ® Shield connector for shielded wire, inner sleeve GSB, outer sleeve GSC, reliable connection. For the processing of shield cable from 1.1 to 9.4 mm dielectric diameter (diameter after removal of the umbrella), telecommunications, Railway Applications,, hard, stable inner sleeve takes the pressure and thus protects the inner conductor.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Inner sleeve
Hints
Outer sleeve must be ordered.
