LAPP ÖLFLEX® CLASSIC 191 Control lead 4 G 1.5 mm² Grey 11138/300 300 m
EAN:
Part number:
Item no:
Product type
Control lead
No. of leads
4 G
Cross section (each core)
1.5 mm²
Cable type
ÖLFLEX® CLASSIC 191
Outside Ø
8.20 mm
Datasheet (PDF)
Number
Total (1 m = € 2.06)
€ 617.65
plus VAT.
Only 3 Set(s) available
Highlights & Details
ÖLFLEX® CLASSIC 191 Control cable
Technical specifications
- Product type
Control lead
- No. of leads
4 G
- Content
300 m
- Cross section (each core)
1.5 mm²
- Cable features
Oil-resistant
Flexible
- Cable type
ÖLFLEX® CLASSIC 191
- Outside Ø
8.20 mm
- Packaged
Yes
- Wire ID code
Black with white numbers according to VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
15
- Halogen-free
No
- Manufacturer part #
11138/300
- Factory colour
Grey
- Insulation material
PVC
- Core layout
Fine-wired strands made of blank copper wires
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Certification marks
UL AWM Style 21098 · CSA AWM I A/B II A/B
- Number-coded
Yes
- Test voltage
4 kV
- Cross section
4 G 1.5 mm²
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+70 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
ÖLFLEX 191 4G1,5
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1334924 LAPP ÖLFLEX® CLASSIC 191 Control lead 4 G 1.5 mm² Grey 11138/300 300 m
User & Safety Instructions
User & Safety Instructions 1334924 LAPP ÖLFLEX® CLASSIC 191 Control lead 4 G 1.5 mm² Grey 11138/300 300 m
Description
High electrical safety through 4 kV test voltage.
Application areas:Tool machines · Used mainly in dry, moist and wet rooms (also water-oil mixtures), but not in the open · For fixed laying as well as also for flexible applications with free, not constantly recurring movement without tensile load or forced guiding, at average mechanical load.
