LEDmaxx ALU1R1S 1x Floor socket incl. CAT5 socket IP20 Aluminium
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
Floor socket
- Light bulb features
incl. CAT5 socket
- Outlets
1
- Nominal voltage
230 V
- Nominal current
16 A
- Mounting type
Recess-mount
Floor
Wall
- Recess diameter
100 mm
- Mounting depth
55 mm
- Factory colour
Aluminium
IP20
- Dim
(Ø x D) 145 mm x 80 mm
- Depth
80 mm
- (Ø)
145 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1759010 LEDmaxx ALU1R1S 1x Floor socket incl. CAT5 socket IP20 Aluminium
User & Safety Instructions
User & Safety Instructions 1759010 LEDmaxx ALU1R1S 1x Floor socket incl. CAT5 socket IP20 Aluminium
Description
The floor and wall mounting socket is equipped with an earthing contact socket with increased touch protection and two module data sockets RJ45 8-pin CAT5 with self-closing dust protection cover. Galvanized mounting box 100x100x55 mm. Cover aluminum cast/ground. Can be driven over. With plug connection 1 - 2.5 mm².
