Legrand Legrand 412828 DIN rail mount timer analogue 250 V
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Automatic summer/winter time adjustment: Yes
- Width in division units: 3
- Nominal switching current at 250 V AC 17 A.
- Supply voltage frequency 50 Hz
- Voltage type of supply voltage: AC
- Contact type: Changer
- Protection class: IP21
- Mounting type: DIN rail
- Product type
DIN rail mount timer
- Operating voltage
250 V
- Channels
1-channel
- Type
analogue
- Type
Legrand 412828
- Manufacturer part #
412828
- Min. power reserve
6 years
- Height
83 mm
- Length
60 mm
- Switching cycle
7 day mode
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2158296 Legrand Legrand 412828 DIN rail mount timer analogue 250 V
User & Safety Instructions
User & Safety Instructions 2158296 Legrand Legrand 412828 DIN rail mount timer analogue 250 V
Description
MicroRex W31 Su/Wi, Plug and Play, analogueue weekly timer with automatic time setting at start-up. Automatic summer/winter time adjustment and automatic time adjustment after chip failure. Precision quartz clock movement with accuracy of +/- 0.2 sec/day. Power reserve 6 years (time buffering in the event of a power failure). For distributor installation, with manual switch: ON-off, with captive switching segments, with LED status display, sealable cover, shortest switching time: 4 hours. Switching output: 1 changer 250V/ 50 Hz, 16 A~ cos phi = 1
