Highlights & Details

Lenovo System x3550 M5 Server

Intel® Xeon® E5-2620V4 Broadwell 8 core(s) / max. 3 GHz
RAM: 16 GB DDR4 SDRAM 2133 MHz
w/o OS

Technical specifications

Product type: Server

Model: System x3550 M5 8869

CPU series: Intel® Xeon®

CPU: Intel® Xeon® E5-2620V4

Processor/type: E5-2620V4

Processor generation: Broadwell

Processor cores (No.): 8 x

CPU speed: 2.1 GHz

CPU turbo clock speed (max.): 3 GHz

CPU cache: 20 MB

: 16 GB

RAM type: DDR4 SDRAM

Memory clock speed: 2133 MHz

No. of memory slots: 24

RAM / Max. upgrade: 384 GB

Onboard graphics card: Yes

SSD connection: SAS

HDD capacity (total): 0 GB

Hard drive: 0 GB

Drive: w/o hard drive

Keyboard layout: Keyboard not included

No. of Gigabit LANs: 4 x

No. of USB A 2.0 ports: 2 x

No. of USB type A 3.1 / 3.2 1st Gen: 3 x

No. of VGA ports: 2 x

No. of USB type A 3.0 ports: 2 x

Interfaces: Gigabit LAN (1 Gbps)
USB A (USB 2.0)
USB A (USB 3.2 1st gen)
VGA
RJ45 management port

Width: 429 mm

Height: 43 mm

Depth: 734 mm

Weight: 13.8 kg

PSU power: 750 W

Operating system (Version): w/o OS

Format: 2.5 inch

Graphics card type: Matrox

No. of PSUs: 1

Graphics card type: G200eR2

RAID levels: 0
1
10

Power consumption (max.): 85 W

10/100/1000 Mbps ports: 4 x

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1852161 Lenovo Server System x3550 M5 Intel® Xeon® E5-2620V4 3 GHz 16 GB RAM 8869EJG-4

User & Safety Instructions

User & Safety Instructions 1852161 Lenovo Server System x3550 M5 Intel® Xeon® E5-2620V4 3 GHz 16 GB RAM 8869EJG-4

Description

Lenovo system X3550 M5. Intel® Xeon® Processor Family: E5 v4, processor frequency: 2.1 GHz, processor: E 5-2620 V4. RAM memory: 16GB, internal memory type: DDR4 SDRAM, memory layout: 1 x 16 GB. Form factor: 2.5" hard disks, hard drives interface: Serial ATA III, Serial Attached SCSI (SAS). Built-in Ethernet connection, wiring technology: 10/100/1000Base-T (X). Power supply: 750W, support for redundant power supply. Housing type: Rack (1U)
