Leuze Electronic 50113436 50113436 Contrast sensor 1 pc(s) (L x W x H) 53 x 30 x 80 mm Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Contrast sensor
Type
50113436
Content
1 pc(s)
Connection
M12 plug
Technical specifications
- Packaging type
Piece
- Product type
Contrast sensor
- Type
50113436
- Content
1 pc(s)
- Connection
M12 plug
- Min. temperature
-25 °C
- Max. temperature
60 °C
- Length
53 mm
- Width
30 mm
- Height
80 mm
- Dim
(L x W x H) 53 x 30 x 80 mm
DC
Other
-25-60 °C
FALSE
50000 Hz
1
Connector M12
NPN
Other
FALSE
12-30 V
Safety class 3
Manual adjustment
Cuboid
Other
Multi-coloured LED
FALSE
FALSE
22 mm
Other
IP67
30 mm
80 mm
53 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2981389 Leuze Electronic 50113436 50113436 Contrast sensor 1 pc(s) (L x W x H) 53 x 30 x 80 mm Piece
Description
Special version: Auto collimation, time function; operating range: 0.018 ... 0.022 m; light source: LED, RGB; supply voltage: 12 ... 30 V, DC; Digital switching outputs: 1 pieces; switching output 1: Transistor, NPN, light/dark switchable; switching frequency: 50,000 Hz; Connection: round plug, M12, 5-pin; dimensions: 30 mm x 80 mm x 53 mm; material housing: metal; operating elements: film keypad
