Leuze Electronic 50142874 Ultrasonic sensor 1 pc(s) 18 - 30 V DC (L x W x H) 96 x 22 x 46.9 mm
Part number:
Item no:
Product type
Ultrasonic sensor
Min. operating voltage
18 V DC
Max. operating voltage
30 V DC
Type
50142874
Connector
M12 connector
Datasheet (PDF)
Technical specifications
- Product type
Ultrasonic sensor
- Type
50142874
- Connector
M12 connector
- Min. operating voltage
18 V DC
- Max. operating voltage
30 V DC
- Operating voltage
18 - 30 V DC
- Outputs
PNP
NPN
- Min. temperature
0 °C
- Max. temperature
60 °C
- Content
1 pc(s)
- Length
96 mm
- Width
22 mm
- Height
46.9 mm
- Dim
(L x W x H) 96 x 22 x 46.9 mm
- Type
Special design
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3818832 Leuze Electronic 50142874 Ultrasonic sensor 1 pc(s) 18 - 30 V DC (L x W x H) 96 x 22 x 46.9 mm
User & Safety Instructions
User & Safety Instructions 3818832 Leuze Electronic 50142874 Ultrasonic sensor 1 pc(s) 18 - 30 V DC (L x W x H) 96 x 22 x 46.9 mm
Description
Physical principle: Ultrasound; application: Glue point controls; Medium: Transparent and non-transparent; special design: EasyTeach function, integrated web crack control, manual fine adjustment of the switching threshold, teach input, warning output; supply voltage: 18 ... 30 V, DC; Teach inputs: 1 St.; Digital switching outputs: 2 St.; Switching output 1: Transistor, push-pull, IO-Link / PNP light-switching (switching on stick), NPN dark-switching (switching on track); Switching output 2: Transistor, push-pull, active low (normal high, event low); Switching frequency: 2,000 Hz; Interface: IO-Link; Connection: Circular, M12, 5-pin; connector outlet: horizontal (parallel to belt run); jaw width: 4 mm; jaw depth: 80 mm; dimensions: 22 mm x 46.9 mm x 96 mm; material housing: metal; operating elements: control keys; protection class: IP 65; approvals: c UL US
