Leuze Electronic Interface 1 pc(s) 549992
EAN:
Part number:
Item no:
Product type
Interface
Type
549992
Min. temperature
-30 °C
Max. temperature
60 °C
Content
1 pc(s)
Technical specifications
- Product type
Interface
- Type
549992
- Min. temperature
-30 °C
- Max. temperature
60 °C
- Content
1 pc(s)
60 mm
38.3 mm
225 mm
TRUE
FALSE
FALSE
FALSE
2
3
FALSE
FALSE
Screw connection
24-24 V
FALSE
Level e
DC
3
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2982952 Leuze Electronic Interface 1 pc(s) 549992
Description
Functions: Sequence-controlled 2-sensor muting, time-controlled 2-sensor muting, sequence-controlled 4-sensor muting, muting-timeout extension, muting-enable function; Restart: automatic, manual; SIL: 3, IEC 61508; Performance Level (PL): e, EN ISO 13849-1; Category: 4, EN ISO 13849; Contacts (normally open contact/opener): OSSDs; Number of safety switching inputs: 2 pieces; number of switching inputs: 8 pieces; number of safety switching outputs (OSSDs): 2 pieces; number of switching outputs: 3 pieces; safety switching output 1: transistor; safety switching output 2: transistor; switching output 1: transistor, PNP; Dimensions: 60 mm x 38.3 mm x 225 mm; Ambient temperature operation: -30 ... 60 °C; approvals: TÜV SÜD, c CSA us
