Leuze Electronic One-way light barrier 50146455 50146455 1 pc(s)
Part number:
Item no:
Product type
One-way light barrier
Max. operating voltage
30 V DC
Connector
M12 connector
Type
50146455
Min. operating voltage
10 V DC
Technical specifications
- Product type
One-way light barrier
- Type
50146455
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Connector
M12 connector
- Enclosure material
Plastic
- Transmitter type
Red light, unpolarised
- Min. temperature
-40 °C
- Max. temperature
60 °C
- Length
30 mm
- Width
15 mm
- Height
42.7 mm
- Dim
(L x W x H) 30 x 15 x 42.7 mm
- Content
1 pc(s)
- Type
Ashlar
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3819398 Leuze Electronic One-way light barrier 50146455 50146455 1 pc(s)
Description
Limit range: 0 ... 30 m; light source: LED, red; supply voltage: 10 ... 30 V, DC; connection: Line with circular plug, 200 mm, M12, PUR, 4 -core, 4-pin; design housing: cubic; dimensions: 15 mm x 42.7 mm x 30 mm; material housing: plastic; ambient temperature operation: -40 ... 60 °C; PROTECTION CLASS IP 69K, IP 67
This text is machine translated.
This text is machine translated.
Hints
For more information on this 50146455, please refer to its datasheet under 'downloadable documents'
