Name: Leuze Electronic Photo sensor 50134608 50134608 Background suppression 1 pc(s)
Brand: Leuze Electronic
SKU: 2983980

A red electronic sensor by Leuze Electronic, model HRTL 118 M12, for object detection, with labels and connections.

Product type

Photo sensor

Functions

Background suppression

Type

50134608

Response time

1 ms

Outputs

2x PNP

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Photo sensor

Type: 50134608

Functions: Background suppression

Response time: 1 ms

Outputs: 2x PNP

Switching frequency: 500 Hz

Enclosure material: Plastic

Transmitter type: Laser diode

Laser class: 2

Wavelength: 655 nm

: 1.2 m

Features: Incl. background suppression

Min. temperature: -40 °C

Max. temperature: 60 °C

Length: 44 mm

Width: 20.5 mm

Height: 76.3 mm

Dim: (L x W x H) 44 x 20.5 x 76.3 mm

Content: 1 pc(s)

: DC

: 100 mA

: Plastic

: FALSE

: 120-1200 mm

: -40-60 °C

: FALSE

: 500 Hz

: 2

: Connector M12

: PNP

: Other

: 10-30 V

: Safety class 3

: Manual adjustment

: None

: None

: Cuboid

: Class 2

: Laser diode, red light

: FALSE

: FALSE

: 1 ms

: FALSE

: 655 nm

: Plastic

: Other

: FALSE

: FALSE

: FALSE

: FALSE

: 20.5 mm

: 76.3 mm

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: 44 mm

: FALSE

: FALSE

: Light switching

: Background fade-out

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2983980 Leuze Electronic Photo sensor 50134608 50134608 Background suppression 1 pc(s)

Description

Limit range: 0.05 ... 1.2 m; light source: Laser, red; protection class: 2; supply voltage: 10 ... 30 V, DC; Digital switching outputs: 2 pieces; switching output 1: Transistor, PNP, light-switching; switching output 2: Transistor, PNP, dark switching; switching frequency: 500 Hz; connection: round plug, M12, Plastic, 4-pin; design: cubic; dimensions: 20.5 mm x 76.3 mm x 44 mm; material housing: plastic; controls: multi-speed spindle; ambient temperature operation: -40 ... 60 °C; PROTECTION CLASS IP 69K, IP 67

This text is machine translated.
