Leuze Electronic Reflective light sensor Ultrasound IO link 50142865
EAN:
Part number:
Item no:
Product type
Reflective light sensor
Outputs
IO link
Model
Ultrasound
Type
50142865
Material properties
nickel galvanized
Technical specifications
- Product type
Reflective light sensor
- Type
50142865
- Outputs
IO link
- Model
Ultrasound
- Material properties
nickel galvanized
- Enclosure material
Zinc (die-cast)
- Length
96 mm
- Width
46.9 mm
- Height
22 mm
- Dim
(L x W x H) 96 x 46.9 x 22 mm
DC
100 mA
0-0 °C
2000 Hz
Connector M12
Anticoincidence
0 mA
18-18 V
22 mm
46.9 mm
96 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2983983 Leuze Electronic Reflective light sensor Ultrasound IO link 50142865
Description
Physical principle: Optical and ultrasound; application: Detection of transparent labels, detection of non-transparent labels; label width, min.: 4 mm ultrasound / 2 mm optical; label gap, min.: 2 mm; Medium: Transparent and non-transparent; special version: Teach input, ALC function (tracking), EasyTeach function, manual fine tuning of the switching threshold, warning output; light source: LED, infrared; supply voltage: 18 ... 30 V, DC; Teach inputs: 1 St.; Digital switching outputs: 2 St.; Switching output 1: Transistor, push-pull, IO-Link / PNP light-switching (switching in gaps), NPN dark-switching (switching on label); Switching output 5: Transistor, push-pull, active low (normal high, event low); switching frequency: 2,000 Hz ultrasound / 9061 Hz optical; Interface: IO-Link; Connection: Circular, M12, 2-pin; Plug outlet: horizontal (parallel to the belt run); jaw width: 4 mm; jaw depth: 80 mm; dimensions: 22 mm x 46.9 mm x 96 mm; material housing: metal, zinc die cast, galvanic nickel coating; operating elements: control keys
