Leuze Electronic Ultrasonic proximity sensor Ultrasound M18 50136084
EAN:
Part number:
Item no:
Product type
Ultrasonic proximity sensor
Switching distance (max.)
400 mm
Model
Ultrasound
(Ø)
18 mm
Type
50136084
Technical specifications
- Product type
Ultrasonic proximity sensor
- Type
50136084
- Switching distance (max.)
400 mm
- Model
Ultrasound
- Size
M18
- Enclosure material
Plastic
- Contact type
1 maker
- Length
91.6 mm
- (Ø)
18 mm
- Dim
(Ø x L) 18 mm x 91.6 mm
DC
100 mA
Plastic
-20-70 °C
10 Hz
-10V ... +10 V
Connector M12
PNP
Normally open contact (NO)
50 mm
Manual adjustment
None
None
Cylinder plain
50 mA
0.5 %
FALSE
10-30 V
Plastic
Other
18 mm
91.6 mm
50-400 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2983898 Leuze Electronic Ultrasonic proximity sensor Ultrasound M18 50136084
Description
Special version: Multiplex operation, synchronous operation; measuring range: 50 ... 400 mm; Geometric resolution: < 2 mm; Supply voltage: 10 ... 30 V, DC; Digital switching outputs: 1 pieces; Analogue output: Voltage; Switch output: Transistor, PNP, NO (NO); In/outputs: 1 pieces; connection: round plug, M12, 5-pin; design: cylindrical, M18; dimensions: 91.6 mm; material housing: plastic; operating elements: control keys
