LevelOne 55051607 IGP-0802 Industrie Switch Network switch 1 GBit/s PoE
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
Network switch
- LAN transfer rate
1000 MBit/s
- Transfer rate
1 GBit/s
- Working principle
Unmanaged switch
- Ethernet ports
8
- PoE ports
8
- 10/100/1000 Mbps ports
8 x
- Auto-uplink at each port
Yes
- Jumbo frames
Yes
- Router features
PoE
- Power supply (LOV)
via DC in
- MAC addresses
8000
- Weight
525 g
- Width
142 mm
- Height
36.2 mm
- Depth
105 mm
- Type
IGP-0802 Industrie Switch
- Interfaces
RJ45
- Factory colour
Multicolour
- Operating voltage
56 V DC
- Max. ambient temperature
75 °C
- Min. ambient temperature
40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1927884 LevelOne 55051607 IGP-0802 Industrie Switch Network switch 1 GBit/s PoE
User & Safety Instructions
User & Safety Instructions 1927884 LevelOne 55051607 IGP-0802 Industrie Switch Network switch 1 GBit/s PoE
Description
LevelOne IGP-0802. Switch type: Unmanaged. Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000), Number of basic switching RJ-45 Ethernet Ports: 8. Full duplex. Mac address table: 8000 entries, routing/switching capacity: 16 Gbit/s. Network standard: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Power over Ethernet (PoE) Wall mounting
