Littelfuse IXBH42N300HV IGBT TO-247HV 3000 V Tube
EAN:
Part number:
Item no:
Packaging type
Tube
Product type
IGBT
Enclosure
TO-247HV
Collector current
104 A
Type
IXBH42N300HV
Technical specifications
- Package type TO-247HV
- VCES - Collector emitter voltage (V) 3000 V
- Current collector @ 25 ℃ (A) 104 A
- VCE(sat) - Collector emitter Saturation Voltage (V) 3 V
- Configuration: Copack (FRED)
- Case Time [Resistive Load] (ns): 610 ns
- Thermal resistance (junction-case) (K/W): 0.25 K/W.
- Driving Voltages (V): 15 V
- Current collector @ 110 ℃ (A) 42 A
- Packaging type
Tube
- Type
IXBH42N300HV
- Product type
IGBT
- Enclosure
TO-247HV
- Manufacturer
Littelfuse
- Collector emitter reverse voltage U(CES)
3000 V
- Collector current
104 A
- Collector-emitter saturation voltage (max.)
3 V
- Type
IGBT
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2960630 Littelfuse IXBH42N300HV IGBT TO-247HV 3000 V Tube
