LogiLink USB-C®, Audio/phono Adapter [1x USB-C® - 1x USB-C® socket, USB-C® socket (Power Delivery)] UA0433
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Only 3 Piece(s) available
Highlights & Details
USB-C adapter with PD charging port, 2x USB-C, max. 60 W, white
- 2-in-1 USB-C adapters for headphones or microphone with additional USB-C port, for instance, to charge a smartphone
- Connection 1 USB-C plug
- Connection 2: 1x USB-C (PD) charging socket 60 W; 1x USB-C socket
- Supports rapid charging with USB (PD) 60 W (20 V/3 A max.)
- OUTPUT: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A (60 W MAX.)
- USB-C bidirectional: Yes
- Compatible with iPhone 15 series, iPad, MacBook, Android mobile phones/tablets with USB-C ports
- Dimensions 2.79 x 2.6 x 0.81 cm (without cable)
- Colour: White
Technical specifications
- Product type
USB-C®
- Connection type
USB-C®
- No. of A connectors
1 x
- Type A
USB-C®
- No. of B connections
1 x
- Type B
USB-C® socket
USB-C® socket (Power Delivery)
- Factory colour
White
- Connector version
straight
- Cable use
USB-C®
Audio/phono
- Version
Adapter
- Range of use
USB adapters
- Cable design
Round
- Depth
8.1 mm
- Height
26 mm
- Audio channels
Stereo
Cable
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3384343 LogiLink USB-C®, Audio/phono Adapter [1x USB-C® - 1x USB-C® socket, USB-C® socket (Power Delivery)] UA0433
User & Safety Instructions
User & Safety Instructions 3384343 LogiLink USB-C®, Audio/phono Adapter [1x USB-C® - 1x USB-C® socket, USB-C® socket (Power Delivery)] UA0433
Description
The USB-C adapter with 60W PD charging port and headset port is a convenient accessory that can be useful in many situations. It combines several functions in one compact device. Thanks to the 60W Power delivery, you can charge your compatible devices, such as Smartphones, tablets or laptops, quickly and efficiently. This is especially convenient when you are traveling and do not have an electrical outlet nearby. Telephone calls via a headset with microphone is not a problem.
