Buy Lumel MA19 150A/60mV MA19 150A/60mV Panel-mounted measuring device 96 x 96, 96 x 96 mm 150 A/DC (60A) Moving coil

Shows an analogue ammeter for alternating current; scale from 0 to 500 amperes. Pointer indicates approximately zero.

Image similar

Datasheet (PDF)

Unavailable

3 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Panel-mounted measuring device 96 x 96, 96 x 96 mm

Assembly dimensions 92 x 92 mm

Technical specifications

With standard AC scale
Connection angle 90°

Product type: Analogue rack-mount meter

Reading type: Amperage

Reading range (max.): 150 A

Dim: (W x H) 96 mm x 96 mm

Recess width: 92 mm

Instrument type: Moving coil

Recess height: 92 mm

Temperature range: -10 to +55 °C

Type: MA19 150A/60mV

Content: 1 pc(s)

Width: 96 mm

Height: 96 mm

Frame width: 96 mm

: Manufacturer's standards (no certificate)

: IP50

Connections: Shunt connection

Assembly dimensions: 92 x 92 mm

Accuracy class: 1.5

Type: MA 19

Reading range: 150 A/DC (60A)

Documents & Downloads

Datasheet

Datasheet 1383507 Lumel MA19 150A/60mV MA19 150A/60mV Panel-mounted measuring device 96 x 96, 96 x 96 mm 150 A/DC (60A) Moving coil

User & Safety Instructions

User & Safety Instructions 1383507 Lumel MA19 150A/60mV MA19 150A/60mV Panel-mounted measuring device 96 x 96, 96 x 96 mm 150 A/DC (60A) Moving coil

Description

The Moving coil meter is suitable for the measurement of direct currents or voltages. The measuring device can be installed in control panels or machines. The front frame, the front windscreen and the scale can be easily replaced.
