Manhattan 154116 2D barcode scanner Corded 1D, 2D LED Black Hand-held USB type A
EAN:
Part number:
Item no:
Barcode Scanner
Highlights & Details
- Makes data entry easier, more efficient and error-free - Ideal for shops and automated processes
- Wide scan field provides for fast, accurate scanning at a range of up to 450 mm
- Detects a wide range of common 1D and 2D symbologies, including UPC, EAN, QR Code, Data Matrix, PDF417 and more
- Casing with protection class IP52 for protection against dust and water in rough environments
- ESD protection up to 16 kV (air) and 8 kV (contact)
Technical specifications
- Product type
2D barcode scanner
- Type
154116
- Type
Hand-held
- Scanning technology
LED
- Readable code types
1D
2D
- Reading distance (max.)
450 mm
- Scanning confirmation
Acoustic
- Scan rate
60 Scans/s
- Cordless scanning
Corded
- Range of use
Libraries
Healthcare
Pharmacies
Logistics
Retail
Manufacturing
- Factory colour
Black
- Interfaces
USB type A
- Cable length
180 cm
- Protection class
IP52
- Width
67 mm
- Height
172 mm
- Depth
87 mm
- Weight
150 g
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3402129 Manhattan 154116 2D barcode scanner Corded 1D, 2D LED Black Hand-held USB type A
Description
Dust-protected 1D/2D USB barcode scanner for more productivity in retail, catering, logistics and demanding environments
The Manhattan 2D LED barcode scanner is the robust solution for optimized, efficient data input. It helps you manage routine tasks and automate paper-based processes. Capture 1D and 2D barcodes from mobile devices, as well as on paper such as sales items, vouchers, store cards, and more. This scanner is suitable for many industries, including retail/checkout systems, healthcare, restaurants, warehousing and logistics.
Fast and precise scanning with every use
Thanks to its wide scanning range and a scanning range of up to 450 mm, it enables fast and precise recordings and thereby reduces errors and delays for a smooth operation.
Versatile compatibility for a wide range of barcode types
Equipped with modern technology, the scanner detects a variety of popular 1D and 2D barcodes including UPC, EAN, QR code, Data Matrix. PDF417 and many more. Whether simple barcodes or complex QR codes - it processes everything precisely and quickly.
Robust design for demanding environments
The scanner is specially designed with its IP52-certified casing for use in demanding environments and offers protection against dust and water spray.
Reliable performance in difficult lighting conditions
Benefit from maximum reliability even under challenging light conditions. With exceptional ambient light tolerance of up to 100,000 lux, the scanner delivers reliable results, even in direct sunlight, ensuring a smooth workflow.
Plug-and-play installation for quick and easy setup
No drivers or additional software are needed – simply connect the USB-A-plug and scanning can start. Compatible with Windows®, MacOS®, Chrome OS™ and Linux®, it integrates seamlessly into existing systems. The cabled USB-connection guarantees reliable performance without changing the battery.
Even more user-friendliness with our barcode scanner holder
For added convenience, combine the scanner with the Manhattan barcode scanner stand #154192 for hands-free operation – Ideal for Hohem environments such as retail or warehousing.
This text is machine translated.
The Manhattan 2D LED barcode scanner is the robust solution for optimized, efficient data input. It helps you manage routine tasks and automate paper-based processes. Capture 1D and 2D barcodes from mobile devices, as well as on paper such as sales items, vouchers, store cards, and more. This scanner is suitable for many industries, including retail/checkout systems, healthcare, restaurants, warehousing and logistics.
Fast and precise scanning with every use
Thanks to its wide scanning range and a scanning range of up to 450 mm, it enables fast and precise recordings and thereby reduces errors and delays for a smooth operation.
Versatile compatibility for a wide range of barcode types
Equipped with modern technology, the scanner detects a variety of popular 1D and 2D barcodes including UPC, EAN, QR code, Data Matrix. PDF417 and many more. Whether simple barcodes or complex QR codes - it processes everything precisely and quickly.
Robust design for demanding environments
The scanner is specially designed with its IP52-certified casing for use in demanding environments and offers protection against dust and water spray.
Reliable performance in difficult lighting conditions
Benefit from maximum reliability even under challenging light conditions. With exceptional ambient light tolerance of up to 100,000 lux, the scanner delivers reliable results, even in direct sunlight, ensuring a smooth workflow.
Plug-and-play installation for quick and easy setup
No drivers or additional software are needed – simply connect the USB-A-plug and scanning can start. Compatible with Windows®, MacOS®, Chrome OS™ and Linux®, it integrates seamlessly into existing systems. The cabled USB-connection guarantees reliable performance without changing the battery.
Even more user-friendliness with our barcode scanner holder
For added convenience, combine the scanner with the Manhattan barcode scanner stand #154192 for hands-free operation – Ideal for Hohem environments such as retail or warehousing.
This text is machine translated.
Features
- General:
- Supports 1D and 2D barcodes
- LED scan light type
- Scan depth (range) 450 mm
- Scanning rate: 60 scans per second
- Resolution
- - 1D: 3 mil/0.076 mm
- - 2D: 7 mil/0.18 mm
- Sensor size 1280 (H) x 800 (V) pixel
- Field of view (FOV): Horizontal -45 degrees, vertical -36 degrees
- 20% contrast ratio (PCR
- Read confirmation: Signal tone and LED
- Ambient light conditions: Up to 100,000 lux (sunlight)
- Impact resistance: 1.2 m on concrete surface
- MTBF: 50,000 hours
- Interface USB-A
- Button: Trigger
- Supported codes
- 1D SYMBOLOGIES: UPC-A, UPC-E, EAN-8/JAN-8, EAN-13/JAN-13, ISSN, UCC/EAN-128, Code 39, Code 39 Full ASCII, Code 128, Interleaved 25, Industrial 25, Matrix 25, Codabar/NW7, code 93, code11, China post, MSI, Telepen, GS1 Databar Omni-directional, GS1 Databar Limited, GS1 Databar extended
- 2D symbologies: Aztec, Data Matrix, MaxiCode, QR Code, PDF417, Micro PDF417, HANXIN, MicroQR Code, dot code, grid matrix
- Physical details
- Dimensions (L x W x H) 172 x 67 x 87 mm
- Cable length: 1,8 m
- Net weight: 220 g
- Gross weight 300 g
- Housing: ABS plastic, protection class IP52
- Ambient conditions
- Operating ambient temperature: -10 – 50 degrees C.
- Ambient temperature during storage: -20 degrees C - 70 degrees C.
- Humidity (non-condensing): 20 - 95% RH
- Electrical details
- Voltage DC 5.0 V.
- Power consumption:
- - 130 mA (standby)
- - Less than 280 mA (operation)
