Manhattan 154185 2D wireless barcode scanner Radio 1D, 2D LED Black Hand-held Radio, USB type A
EAN:
Part number:
Item no:
Barcode Scanner
Highlights & Details
- Makes data entry easier, more efficient and error-free - Ideal for shops and automated processes
- Wide scan field provides for fast, accurate scanning at a range of up to 450 mm
- Detects a wide range of common 1D and 2D symbologies, including UPC, EAN, QR Code, Data Matrix, PDF417 and more
- Casing with protection class IP52 for protection against dust and water in rough environments
- Highest ambient light tolerance of 100,000 lux for reliable scans even in direct sunlight
Technical specifications
- Product type
2D wireless barcode scanner
- Type
154185
- Type
Hand-held
- Scanning technology
LED
- Readable code types
1D
2D
- Reading distance (max.)
450 mm
- Scanning confirmation
Acoustic
- Scan rate
60 Scans/s
- Cordless scanning
Radio
100 m
- Range of use
Libraries
Healthcare
Pharmacies
Logistics
Retail
Manufacturing
- Factory colour
Black
- Interfaces
Radio
USB type A
- Cable length
100 cm
- Protection class
IP52
- Width
67 mm
- Height
172 mm
- Depth
87 mm
- Weight
195 g
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3402131 Manhattan 154185 2D wireless barcode scanner Radio 1D, 2D LED Black Hand-held Radio, USB type A
Description
Robust 1D wireless / 2D USB barcode scanner for more productivity in retail, hospitality, logistics and harsh environments
The Manhattan wireless 2D long-range LED bar-code scanner is your robust solution for optimized data entry, increased efficiency and automation of paper-based processes. Scan bar codes from mobile devices, merchandise, vouchers, loyalty cards and more. This scanner is designed for various industries such as retail/Point-of-sale, healthcare, catering, warehousing and logistics.
Radio connection with computers and mobile devices
For a classical USB Plug-&-Play installation, simply plug the nano-receiver in a USB-A port on your PC, MacBook or laptop. Alternatively, you can pair the scanner directly to all devices via wireless 4.2, including your iPad® and Android tablets. The transfer range from your host device to the scanner is up to 100 m with the included 2.4 GHz RF dongle or up to 50 m with wireless 4.2.
Fast and precise scans
A wide scanning field and a scanning depth of up to 450 mm guarantee precise data acquisition, quickly and without typos.
Versatile compatibility for many types of code
Thanks to the latest technology, the scanner detects many common 1D and 2D symbologies, including UPC, EAN, QR code, Data Matrix, PDF417 and more. Whether it's barcodes or complex QR codes, it can handle everything quickly and precisely.
Robust design for dusty and wet environments
With an IP52 enclosure, this scanner is designed for harsh environments and offers protection against dust and water.
Reliable performance in all lighting conditions
With a very high tolerance for ambient light up to 100,000 Lux you can scan reliably even in direct sunlight.
Increased comfort with our barcode scanner holder
For additional comfort, you can use the Manhattan barcode scanner stand #154192 for hands-free operation, Ideal for shops with a lot of public traffic or warehouse with Hohem flow of goods.
This text is machine translated.
The Manhattan wireless 2D long-range LED bar-code scanner is your robust solution for optimized data entry, increased efficiency and automation of paper-based processes. Scan bar codes from mobile devices, merchandise, vouchers, loyalty cards and more. This scanner is designed for various industries such as retail/Point-of-sale, healthcare, catering, warehousing and logistics.
Radio connection with computers and mobile devices
For a classical USB Plug-&-Play installation, simply plug the nano-receiver in a USB-A port on your PC, MacBook or laptop. Alternatively, you can pair the scanner directly to all devices via wireless 4.2, including your iPad® and Android tablets. The transfer range from your host device to the scanner is up to 100 m with the included 2.4 GHz RF dongle or up to 50 m with wireless 4.2.
Fast and precise scans
A wide scanning field and a scanning depth of up to 450 mm guarantee precise data acquisition, quickly and without typos.
Versatile compatibility for many types of code
Thanks to the latest technology, the scanner detects many common 1D and 2D symbologies, including UPC, EAN, QR code, Data Matrix, PDF417 and more. Whether it's barcodes or complex QR codes, it can handle everything quickly and precisely.
Robust design for dusty and wet environments
With an IP52 enclosure, this scanner is designed for harsh environments and offers protection against dust and water.
Reliable performance in all lighting conditions
With a very high tolerance for ambient light up to 100,000 Lux you can scan reliably even in direct sunlight.
Increased comfort with our barcode scanner holder
For additional comfort, you can use the Manhattan barcode scanner stand #154192 for hands-free operation, Ideal for shops with a lot of public traffic or warehouse with Hohem flow of goods.
This text is machine translated.
Features
- General:
- Supports 1D and 2D barcodes
- LED scan light type
- Scan depth (range) 450 mm
- Scanning rate: 60 scans per second
- Resolution
- - 1D: 3 mil/0.076 mm
- - 2D: 7 mil/0.18 mm
- Sensor size 1280 (H) x 800 (V) pixel
- Field of view (FOV): Horizontal -45 degrees, vertical -36 degrees
- 20% contrast ratio (PCR
- Read confirmation: Signal tone and LED
- Ambient light conditions: Up to 100,000 lux (sunlight)
- Impact resistance: 1.2 m on concrete surface
- MTBF: 50,000 hours
- Li-Ion 3.7 V/2000 mA (built-in)
- Charging port USB-C
- Battery charging time: Approx. 5 hours
- Button: Trigger
- Supported codes
- 1D SYMBOLOGIES: UPC-A, UPC-E, EAN-8/JAN-8, EAN-13/JAN-13, ISSN, UCC/EAN-128, Code 39, Code 39 Full ASCII, Code 128, Interleaved 25, Industrial 25, Matrix 25, Codabar/NW7, code 93, code11, China post, MSI, Telepen, GS1 Databar Omni-directional, GS1 Databar Limited, GS1 Databar extended
- 2D symbologies: Aztec, Data Matrix, MaxiCode, QR Code, PDF417, Micro PDF, HANXIN, MicroQR Code, Dotcode, GridMatrix
- Supports OCR B characters
- Ambient conditions
- Operating ambient temperature: -10 – 50 degrees C.
- Ambient temperature during storage: -20 - 70 degrees C.
- Humidity (non-condensing): 20 - 95% RH
- Electrical details
- Voltage DC 5.0 V.
- Power consumption:
- - 130 mA (standby)
- - Less than 280 mA (operation)
Scope of delivery
- 2D LED long range barcode scanner
- Charging cable, USB-A to USB-C, 1 m
- User manual.
