Manhattan 2D LED-Barcodescanner 320mm Scanreichweite integriertes 1,4m USB-A-Kabel schwarz 2D barcode scanner Corded 1D,
EAN:
Part number:
Item no:
Barcode Scanner
Highlights & Details
- Makes data entry easier, more efficient and error-free - Ideal for shops and automated processes
- Wide scan field provides for fast, accurate scanning at a range of up to 320 mm
- Detects a wide range of common 1D and 2D symbologies, including UPC, EAN, QR Code, Data Matrix, PDF417 and more
- Highest ambient light tolerance of 100,000 lux for reliable scans even in direct sunlight
- Keyboard Wedge Decoder displays data as if it had been entered directly through the keyboard
Technical specifications
- Product type
2D barcode scanner
- Type
2D LED-Barcodescanner 320mm Scanreichweite integriertes 1,4m USB-A-Kabel schwarz
- Type
Hand-held
- Scanning technology
LED
- Readable code types
1D
2D
- Reading distance (max.)
320 mm
- Scanning confirmation
Acoustic
- Scan rate
100 Scans/s
- Cordless scanning
Corded
- Range of use
Libraries
Healthcare
Pharmacies
Logistics
Retail
Manufacturing
- Factory colour
Black
- Interfaces
USB type A
- Cable length
140 cm
- Width
70 mm
- Height
150 mm
- Depth
95 mm
- Weight
160 g
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3402128 Manhattan 2D LED-Barcodescanner 320mm Scanreichweite integriertes 1,4m USB-A-Kabel schwarz 2D barcode scanner Corded 1D,
Description
Affordable 1D/2D USB barcode scanner for increased productivity in retail, catering and logistics
The Manhattan 2D LED barcode scanner is your entry-level solution for optimized, efficient data input. It helps you manage routine tasks and automate paper-based processes. Capture 1D and 2D barcodes from mobile devices, as well as on paper such as sales items, vouchers, store cards, and more. This scanner is suitable for many industries, including retail/checkout systems, healthcare, restaurants, warehousing and logistics.
Fast and precise scanning with every use
Thanks to its wide scanning range and a scanning range of up to 320 mm, it enables fast and precise recordings and thereby reduces errors and delays for a smooth operation.
Versatile compatibility for a wide range of barcode types
Equipped with modern technology, the scanner detects a variety of popular 1D and 2D barcodes including UPC, EAN, QR code, Data Matrix. PDF417 and many more. Whether simple barcodes or complex QR codes - it processes everything precisely and quickly.
Reliable performance in difficult lighting conditions
Benefit from maximum reliability even under challenging light conditions. With exceptional ambient light tolerance of up to 100,000 lux, the scanner delivers reliable results, even in direct sunlight, ensuring a smooth workflow.
Plug-and-play installation for quick and easy setup
No drivers or additional software are needed – simply connect the USB-A-plug and scanning can start. Compatible with Windows®, MacOS®, Chrome OS™ and Linux®, it integrates seamlessly into existing systems. The cabled USB-connection guarantees reliable performance without changing the battery.
Even more user-friendliness with our barcode scanner holder
For added convenience, combine the scanner with the Manhattan barcode scanner stand #154192 for hands-free operation – Ideal for Hohem environments such as retail or warehousing.
This text is machine translated.
The Manhattan 2D LED barcode scanner is your entry-level solution for optimized, efficient data input. It helps you manage routine tasks and automate paper-based processes. Capture 1D and 2D barcodes from mobile devices, as well as on paper such as sales items, vouchers, store cards, and more. This scanner is suitable for many industries, including retail/checkout systems, healthcare, restaurants, warehousing and logistics.
Fast and precise scanning with every use
Thanks to its wide scanning range and a scanning range of up to 320 mm, it enables fast and precise recordings and thereby reduces errors and delays for a smooth operation.
Versatile compatibility for a wide range of barcode types
Equipped with modern technology, the scanner detects a variety of popular 1D and 2D barcodes including UPC, EAN, QR code, Data Matrix. PDF417 and many more. Whether simple barcodes or complex QR codes - it processes everything precisely and quickly.
Reliable performance in difficult lighting conditions
Benefit from maximum reliability even under challenging light conditions. With exceptional ambient light tolerance of up to 100,000 lux, the scanner delivers reliable results, even in direct sunlight, ensuring a smooth workflow.
Plug-and-play installation for quick and easy setup
No drivers or additional software are needed – simply connect the USB-A-plug and scanning can start. Compatible with Windows®, MacOS®, Chrome OS™ and Linux®, it integrates seamlessly into existing systems. The cabled USB-connection guarantees reliable performance without changing the battery.
Even more user-friendliness with our barcode scanner holder
For added convenience, combine the scanner with the Manhattan barcode scanner stand #154192 for hands-free operation – Ideal for Hohem environments such as retail or warehousing.
This text is machine translated.
Features
- General:
- Supports 1D and 2D barcodes
- LED scan light type
- Scan depth (range) 320 mm
- Scanning rate: 100 scans per second
- Resolution
- - 1D: 4 mil/0.1 mm
- - 2D: 6.67 mil/0.17 mm
- Sensor size 640 (H) x 480 (V) pixel
- Field of view (FOV): Horizontal -36 degrees, vertical -28 degrees
- 25% contrast ratio (PCR
- Motion tolerance: 25 cm per second
- Read confirmation: Signal tone and LED
- Ambient light conditions: Up to 100,000 lux (sunlight)
- Impact resistance: 1.2 m on concrete surface
- MTBF: 50,000 hours
- Interface USB-A
- Button: Trigger
- Supported codes
- 1D SYMBOLOGIES: UPC-A, UPC-E, EAN-8/JAN-8, EAN-13/JAN-13, ISSN, Code 39, Code 39 Full ASCII, Code 128, Interleaved 25, Industrial 25, Matrix 25, Codabar/NW7, code 93, Code11, MSI, GS1 DataBar-14/Limited/Expanded
- 2D symbologies: QR Code, MicroQR Code, PDF417, Micro PDF417, Data Matrix, Aztec
- Ambient conditions
- Operating ambient temperature: -20 – 50 degrees C.
- Ambient temperature during storage: -20 degrees C - 60 degrees C.
- Humidity (non-condensing): 5 - 95% RH
- Electrical details
- Voltage DC 5.0 V.
- Power consumption:
- - 57 mA (standby)
- - Less than 130 mA (operation)
