Manhattan Manhattan USB-A Automatic Sharing Switch, 2x USB-B Ports, 480 Mbps (USB 2.0) 2 ports USB 2.0 changeover switch
EAN:
Part number:
Item no:
Datasheet (PDF)
Manhattan 2-Port USB 2.0 SWITCH
Highlights & Details
- Share a USB device enables two computers
- Individual switch for the selection of USB devices per computer
- Idle time-out switch
- Easy to read LED status display
- Surge protection and hot-swappable
- Compatible with all computers with a USB connection.
- Plug and Play; Windows compatible - requires no external power supply
Technical specifications
- Ports: 1 x USB type A, 2x USB type B
- Product type
USB 2.0 changeover switch
- No. of switchable PCs
2
- No. of inputs
1 x
- Interfaces (input)
USB A (USB 2.0)
- No. of outputs
2 x
- Interfaces (output)
USB A (USB 2.0)
- Switch function
Automatic
Key
- Power supply (LOV)
via USB
- Distributor/switch features
PC-controlled
- Factory colour
Black
- Weight
74 g
- Width
43 mm
- Height
20 mm
- Depth
68 mm
- Port
2 ports
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1404087 Manhattan Manhattan USB-A Automatic Sharing Switch, 2x USB-B Ports, 480 Mbps (USB 2.0) 2 ports USB 2.0 changeover switch
User & Safety Instructions
User & Safety Instructions 1404087 Manhattan Manhattan USB-A Automatic Sharing Switch, 2x USB-B Ports, 480 Mbps (USB 2.0) 2 ports USB 2.0 changeover switch
Description
Easy access of two PCs to a USB device
The Manhattan 2-Port USB 2.0 switch enables the comfortable share a USB peripheral device between two PCs or notebooks - especially convenient for the common use of a printer, scanner, an external hard disk, and more. The changeover is done easily either by using the on-screen menu or directly with the buttons on the switch itself. Via Plug & Play installation is in no time at all. The necessary USB cable are included in the delivery, driver, or an external power supply are not needed.
This text is machine translated.
The Manhattan 2-Port USB 2.0 switch enables the comfortable share a USB peripheral device between two PCs or notebooks - especially convenient for the common use of a printer, scanner, an external hard disk, and more. The changeover is done easily either by using the on-screen menu or directly with the buttons on the switch itself. Via Plug & Play installation is in no time at all. The necessary USB cable are included in the delivery, driver, or an external power supply are not needed.
This text is machine translated.
Features
- Standards and certificates: USB 2.0, FCC, CE, RoHS, WEEE
- Transmission speeds: 1.5/12/480 Mbps
- 2 LEDs
- 2 mechanical switch
- Power supply via USB
- Cable length type A USB to type B: 1.5 m
- Housing: ABS plastic
- Power supply via USB-Port: 500 mA
Scope of delivery
- USB cable
- Software CD
- User manual.
- 2-Port USB 2.0 SWITCH
System requirements
- Windows XP or later
