MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
4 Piece(s)
Sales and shipping:
Number
Total (€ 63.86 / piece)
€
Only 4 Piece(s) available
Highlights & Details
MEANWELL DC/DC converter series DDR-120 for DIN rail Single Output Input voltage ratio: 2:1 Power: 120 W
- For DIN rail mounting.
- Can be used on DIN-rail TS-35/7.5 or 15 can be installed
- Width of only 32 mm
- 2:1 input voltage range
- 150% peak load capacity
- Regulated output voltage
- Cooling by free air convection
- Input/output insulation 4000 V
- Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
- This text is machine translated.
Technical specifications
- Nominal input voltage
48 V/DC
- Product type
Rail mounted DC/DC converter (DIN)
- Min. input voltage
33.6 V DC
- Output voltage
48 V DC
- Input voltage
33,6-64,2 V DC
- Input voltage (max.)
67.2 V DC
- Max. output current
2.5 A
- Output current (max.) - rounded
2.5 A
120 W
- Output type (power supply units)
Adjustable
- Output voltage (nominal)
48 V DC
- No. of outputs
1 x
- Connection
Clamp
- Dim
(L x W x H) 32 x 102 x 125.2 mm
- Weight
510 g
- Output voltage (max.)
56 V DC
- Output voltage (min.)
48 V DC
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-40 °C
- Manufacturer part #
DDR-120C-48
- Content
1 pc(s)
- MTBF
214600 h
- PSU features
DC-to-DC converter
Regulated
Adjustable voltage output
- Width
102 mm
- Height
125.2 mm
- Length
32 mm
- Type
DDR-120C-48
- Efficiency
92 %
Documents & Downloads
Datasheet
Datasheet 2113421 MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2113421 MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2113421 MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)
Description
Features
- Can be used on DIN-rail TS-35/7.5 or 15 can be installed
- Width of only 32 mm
- 2:1 input voltage range
- 150% peak load capacity
- Regulated output voltage
- Cooling by free air convection
- Input/output insulation 4000 V
- Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
