MEAN WELL DDR-30G-5 Rail mounted DC/DC converter (DIN) 5 V DC 6 A 30 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 25.20
3
4% = € 1.09
€ 24.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 25.20 / piece)
€ 25.20
plus VAT.
14-day return policy included
Highlights & Details
MEANWELL DC/DC converter series DDR-30 for DIN rail Single Output Input voltage ratio: 4:1 Power: 30 W
- For DIN rail mounting.
- Can be used on DIN-rail TS-35/7.5 or 15 can be installed
- Width of only 35 mm
- Wide input voltage range 4:1
- No minimum load required
- Regulated output voltage (±10%)
- Cooling by free air convection
- Input/output insulation 4000 V
- Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
- This text is machine translated.
Technical specifications
- Nominal input voltage
24 V/DC
- Product type
Rail mounted DC/DC converter (DIN)
- Min. input voltage
9 V DC
- Output voltage
5 V DC
- Input voltage
9-36 V DC
- Input voltage (max.)
36 V DC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
30 W
- Output type (power supply units)
Adjustable
- Output voltage (nominal)
5 V DC
- No. of outputs
1 x
- Connection
Clamp
- Dim
(L x W x H) 35 x 54.5 x 90 mm
- Weight
120 g
- Output voltage (max.)
5.5 V DC
- Output voltage (min.)
4.5 V DC
- Operating temperature (max.)
+85 °C
- Operating temperature (min.)
-40 °C
- Manufacturer part #
DDR-30G-5
- Content
1 pc(s)
- MTBF
483300 h
- PSU features
DC-to-DC converter
Regulated
Adjustable voltage output
- Width
54.5 mm
- Height
90 mm
- Length
35 mm
- Type
DDR-30G-5
- Efficiency
85 %
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2113539 MEAN WELL DDR-30G-5 Rail mounted DC/DC converter (DIN) 5 V DC 6 A 30 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2113539 MEAN WELL DDR-30G-5 Rail mounted DC/DC converter (DIN) 5 V DC 6 A 30 W No. of outputs:1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2113539 MEAN WELL DDR-30G-5 Rail mounted DC/DC converter (DIN) 5 V DC 6 A 30 W No. of outputs:1 x Content 1 pc(s)
Description
Features
- Can be used on DIN-rail TS-35/7.5 or 15 can be installed
- Width of only 35 mm
- Wide input voltage range 4:1
- No minimum load required
- Regulated output voltage (±10%)
- Cooling by free air convection
- Input/output insulation 4000 V
- Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
