MEAN WELL DETN01N-12 DC/DC converter (module) 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.03
5
6% = € 0.32
€ 4.71
10
9% = € 0.46
€ 4.57
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.03 / piece)
€ 5.03
plus VAT.
Only 1 Piece(s) available
Highlights & Details
MEANWELL SMD DC/DC converter modules series DETN01 SMD Case Dual Output Input voltage ratio: 1:1 Power: 1 W
- In the SMD housing
- For direct PCB mounting
- Input/output insulation 3000 V DC
- According to EN 55032 Class B transmitted without additional components
- Efficiency up to 83%
- Circuit breaker
- Low Cost
Technical specifications
- Product type
DC/DC converter (module)
- Type
DETN01N-12
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
2 x
- Max. output current
42 mA
- Output current (max.) - rounded
42 mA
- Efficiency (max.)
77 %
1 W
- Insulation voltage
3000 V DC
- Connection
Pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+90 °C
- Dim
(L x W x H) 15.24 x 10.9 x 7.1 mm
- Height
7.1 mm
- Length
15.24 mm
- Width
10.9 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output current (min.)
4.2 mA
- Weight
1.2 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2143488 MEAN WELL DETN01N-12 DC/DC converter (module) 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2143488 MEAN WELL DETN01N-12 DC/DC converter (module) 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2143488 MEAN WELL DETN01N-12 DC/DC converter (module) 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
MEAN CORRUGATED has its program of converters the unregulated 1W SMD DC/DC converter with Dual Output DETN01. In comparison to the converters of the last generation DET01, the new series of DETN01 a larger operating temperature range (-40 to +90 °C) and a higher degree of efficiency (up to 83%). In addition, the pin assignment for the new series DETN01 identical to the original DET01 converters, so that a redesign of the circuit board layouts is necessary in order to use the new converter. Suitable applications include IoT, electronics, telecommunications, networking, industrial control and distributed power architectures.
This text is machine translated.
This text is machine translated.
Features
- In the SMD housing
- For direct PCB mounting
- Input/output insulation 3000 V DC
- According to EN 55032 Class B transmitted without additional components
- Efficiency up to 83%
- Circuit breaker
