MEAN WELL DKMW15F-12 DC/DC converter 24 V 12 V 0.625 A 15 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Mean Well DC/DC converter regulated -12 V -0.625 A 1"*1" 3,000 V.
- Application: ITE, Industry
- This text is machine translated.
Technical specifications
- Connection type, input: THTConnection type, output: THTCapacitive load, max. 470 µF
- Product type
DC/DC converter
- Type
DKMW15F-12
- Nominal voltage
24 V
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
12 V
- Max. output current
0.625 A
- Output current (max.) - rounded
625 mA
- Efficiency (max.)
88 %
15 W
- Insulation voltage
3.000 V
- Dim
(L x W x H) 25.40 x 25.40 x 10.20 mm
- Height
10.20 mm
- Length
25.40 mm
- Width
25.40 mm
- Weight
20 g
- Content
1 pc(s)
- Max. temperature
+85 °C
- Min. temperature
-40 °C
