MEAN WELL DPBW03W8-15 DC/DC converter 0.100 A 3 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- REMOTE Function
- Product type
DC/DC converter
- Type
DPBW03W8-15
- Max. output current
0.100 A
- Output current (max.) - rounded
100 mA
3 W
- Enclosure
SIP 8
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15 V
- Output voltage (min.)
-15 V
- Output current (min.)
-0.100 A
- Weight
4.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3556665 MEAN WELL DPBW03W8-15 DC/DC converter 0.100 A 3 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3556665 MEAN WELL DPBW03W8-15 DC/DC converter 0.100 A 3 W Content 1 pc(s)
Description
The DBBW03W8 series is an isolated and regulated 3W module DC-DC converter in the SIP8-casing. They have international standard pinings, a high degree of efficiency of up to 85%, a wide operating temperature range of -40°C+90°C, 3VDE I/P-O/P isolation voltage, conformity with BS EN/EN55022 radiated class A without additional components, permanent short-circuit protection, etc. DBBW03W8 have an ultra-wide input range of 8:1 (9-75Vdc) and various output voltages, +-5V/4+-12V/+-15V for dual outputs suitable for all types of systems such as industrial control, telecommunications, distributed power systems, etc.
