MEAN WELL DRA-60-12 Rail mounted PSU (DIN) 12 V DC 5 A 60 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DIN-Rail Mounting Single Output 1-phase power: 60 W
- Directly on the DIN-rail mountable
- Closed design, touch-proof screw terminals
- Universal input
- Output voltage can be set via built-in potentiometer
- Output current adjustable via external 1...10 VDC, PWM signal of the resistance.
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- LED display for power-on
Technical specifications
- Nominal input voltage
115 V/AC
230 V/AC
- Type
Pulsed
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
90 V AC
- Output voltage
12 V DC
- Input voltage
90-264 V/AC, 47-63Hz
- Input voltage (max.)
264 V AC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
60 W
- Output type (power supply units)
Adjustable
- Phases
1
- Output voltage (nominal)
12 V DC
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 100 x 90 x 40 mm
- Weight
300 g
- Output voltage (max.)
15 V DC
- Output voltage (min.)
12 V DC
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
+70 °C
- Min. operating temperature (derating)
-30 °C
- Operating temperature (min.)
-30 °C
- Manufacturer part #
DRA-60-12
- Content
1 pc(s)
- MTBF
436400 h
- PSU features
Adjustable voltage output
- Width
90 mm
- Height
40 mm
- Length
100 mm
- Max. temperature
70 °C
- Min. temperature
-30 °C
- Type
DRA-60-12
- Efficiency
87 %
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1837938 MEAN WELL DRA-60-12 Rail mounted PSU (DIN) 12 V DC 5 A 60 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1837938 MEAN WELL DRA-60-12 Rail mounted PSU (DIN) 12 V DC 5 A 60 W No. of outputs:1 x Content 1 pc(s)
Conformity certificate
Conformity certificate 1837938 MEAN WELL DRA-60-12 Rail mounted PSU (DIN) 12 V DC 5 A 60 W No. of outputs:1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1837938 MEAN WELL DRA-60-12 Rail mounted PSU (DIN) 12 V DC 5 A 60 W No. of outputs:1 x Content 1 pc(s)
Description
In addition to the usual functions of DIN rail power supplies, such as the output voltage adjustment, the series DRA-40 also has an output power adjustment. Thus, the output current can be adjusted through external voltage 1-10 V DC, PWM signal or resistance and offers the user to provide flexibility.
You can on TS-35/7.5 or TS-35/15 DIN rail mounted, have a 90-264 V AC input voltage range and 12 or 24 V DC output voltage. Thanks to its high efficiency of up to 87%, the power supplies also in ambient temperatures from -30°C to +70°C with simple air convection.
Other features are short-circuit, overload and overvoltage protection and an LED display for power on.
The power supply units are certified in accordance with UL/CUL/CB/TÜV/CE and meet the requirements of IEC 60950-1 limited power source (LPS). Suitable applications are machine test systems and plant cultivation systems with LED light source.
This text is machine translated.
You can on TS-35/7.5 or TS-35/15 DIN rail mounted, have a 90-264 V AC input voltage range and 12 or 24 V DC output voltage. Thanks to its high efficiency of up to 87%, the power supplies also in ambient temperatures from -30°C to +70°C with simple air convection.
Other features are short-circuit, overload and overvoltage protection and an LED display for power on.
The power supply units are certified in accordance with UL/CUL/CB/TÜV/CE and meet the requirements of IEC 60950-1 limited power source (LPS). Suitable applications are machine test systems and plant cultivation systems with LED light source.
This text is machine translated.
Features
- Directly on the DIN-rail mountable
- Closed design, touch-proof screw terminals
- Universal input
- Output voltage can be set via built-in potentiometer
- Output current adjustable via external 1...10 VDC, PWM signal of the resistance.
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- LED display for power-on
