MEAN WELL DRS-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Mean Well UPS 480 W 48 V 10 A external energy storage
- AC-OK signalDC-OK signalFan-freeProgrammable
- This text is machine translated.
Technical specifications
- 2.7 AExternal energy storage
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
90 V AC
127 V DC
- Input voltage (max.)
305 V AC
431 V DC
- Max. output current
10 A
- Output current (max.) - rounded
10 A
480 W
- Output type (power supply units)
Fixed voltage
- Output voltage (nominal)
48 V
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 150.70 x 110 x 125.20 mm
- Weight
1650 g
- Output voltage (max.)
48 V DC
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-30 °C
- Manufacturer part #
DRS-480-48
- Content
1 pc(s)
- Width
110 mm
- Height
125.20 mm
- Length
150.70 mm
Protection class I
- Type
DRS-480-48
- Efficiency
93.5 %
- UKCA
yes
