MEAN WELL ELG-200-12DA-3Y LED transformer, LED driver Constant voltage, Constant current 192 W 16 A 6 - 12 V DC DALI, Su
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED switching power supply ELG-200-12 AS-3Y
- Constant voltage, Constant current
- 6 - 12 V DC
- 16 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 244 x 71 x 37.5 mm
- Factory colour
Metal
- Output voltage (max.)
12 V DC
- Output voltage (min.)
6 V DC
- Max. output current
16 A
- Output current (max.) - rounded
16 A
- Operating voltage
115 V AC
230 V AC
- Protection class
I
- LED driver features
DALI
Suitable for flammable surfaces
PFC circuit
Surge protection
Overvoltage
Outdoor
IP67
- Connection
Open end cable
- Max. power
192 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
100 V AC
- Weight
1.050 g
- Power (min.)
144 W
- Power range
144 up to 192 W
- Type
Synchronised
- Width
71 mm
- Height
37.5 mm
- Length
244 mm
- Max. temperature
90 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1646006 MEAN WELL ELG-200-12DA-3Y LED transformer, LED driver Constant voltage, Constant current 192 W 16 A 6 - 12 V DC DALI, Su
User & Safety Instructions
User & Safety Instructions 1646006 MEAN WELL ELG-200-12DA-3Y LED transformer, LED driver Constant voltage, Constant current 192 W 16 A 6 - 12 V DC DALI, Su
Information
Information 1646006 MEAN WELL ELG-200-12DA-3Y LED transformer, LED driver Constant voltage, Constant current 192 W 16 A 6 - 12 V DC DALI, Su
Warranty Terms
Warranty Terms 1646006 MEAN WELL ELG-200-12DA-3Y LED transformer, LED driver Constant voltage, Constant current 192 W 16 A 6 - 12 V DC DALI, Su
Description
The LED power supplies in IP67 Aluminum housing meet the standards EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13, and are thus used for LED lighting applications.
This text is machine translated.
This text is machine translated.
Features
- Metal housing
- Overload protection by circuit breaker (Hiccup), auto recovery
- Protected against short circuit, overload, over voltage
- For LED lighting applications
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
- Corresponds to 6 kV surge immunity level IEC61000-4-5.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
