MEAN WELL ELG-200-C2100B-3Y LED driver Constant current 2100 W 2100 mA 48 - 96 V DC 3-in-1 dimmer, dimmable, Suitable fo
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 50.41 / piece)
€ 50.41
plus VAT.
Only 3 Piece(s) available
Highlights & Details
ELG-200-C2100B-3Y
- Constant current
- 48 - 96 V DC
- 2100 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 244 x 71 x 37.5 mm
- Factory colour
Metal
- Output voltage (max.)
96 V DC
- Output voltage (min.)
48 V DC
- Test mark
CB, MM, UL, ENEC
- Max. output current
2100 mA
- Output current (max.) - rounded
2.1 A
- Operating voltage
230 V AC
115 V AC
- LED driver features
3-in-1 dimmer
dimmable
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
Surge protection
Overvoltage
IP67
- Connection
Open end cable
- Max. power
2100 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
100 V AC
142 V DC
- Weight
1220 g
- Power range
2100 W (max)
- Type
Pulsed
- Width
71 mm
- Height
37.5 mm
- Length
244 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2176625 MEAN WELL ELG-200-C2100B-3Y LED driver Constant current 2100 W 2100 mA 48 - 96 V DC 3-in-1 dimmer, dimmable, Suitable fo
User & Safety Instructions
User & Safety Instructions 2176625 MEAN WELL ELG-200-C2100B-3Y LED driver Constant current 2100 W 2100 mA 48 - 96 V DC 3-in-1 dimmer, dimmable, Suitable fo
Warranty Terms
Warranty Terms 2176625 MEAN WELL ELG-200-C2100B-3Y LED driver Constant current 2100 W 2100 mA 48 - 96 V DC 3-in-1 dimmer, dimmable, Suitable fo
Description
With the ELG series from MEAN WELL, we offer LED power supplies for you, which are characterized by their variety. In addition to the well-known versions CV+CC (constant voltage and constant current) and CC as analogueue dimmable and non-dimmable version, A DA version is also available that can be controlled digitally via the Dali bus. With a set-up time of less than 500ms and a standby consumption of less than 0.5W, the ELG series of power supplies also meet the limit value of the 2009/125/EC Ecodesign Directive, which was tightened in September 2016.
This text is machine translated.
This text is machine translated.
Features
- IP67
- Dimming via control cable, 3 in 1 dimming function (0...10V DC, PWM, 100k Ohm potentiometer)
- Protective conductor in the primary cable
- Constant current
- Independant operating device
- Wide range input
- Metal housing
- Overload protection by current limitation, auto recovery
- Protected against short-circuit, overload, overvoltage, Overtemperature
- Built-in PFC circuit
- Suitable for LED lighting applications
- SELV compliant
- conforms to 6kV Surge Immunity Level
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
