MEAN WELL ELG-75-12B-3Y LED driver Constant voltage, Constant current 60.0 W 5 A 6 - 12 V DC dimmable, PFC circuit, Surg
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED switching power supply ELG-75-12B-3Y
- Constant voltage, Constant current
- 6 - 12 V DC
- 5 A
Technical specifications
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 180 x 63 x 35.5 mm
- Factory colour
Aluminium
- Output voltage (max.)
12 V DC
- Output voltage (min.)
6 V DC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Operating voltage
115 V AC
230 V AC
- Protection class
I
- LED driver features
dimmable
PFC circuit
Surge protection
Approved for use on furniture
IP67
- Connection
Open end cable
- Max. power
60.0 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
100 V AC
- Inputs
1
- Weight
800 g
- Power range
60.0 W (max)
- Type
Pulsed
- Width
63 mm
- Height
35.5 mm
- Length
180 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1714192 MEAN WELL ELG-75-12B-3Y LED driver Constant voltage, Constant current 60.0 W 5 A 6 - 12 V DC dimmable, PFC circuit, Surg
User & Safety Instructions
User & Safety Instructions 1714192 MEAN WELL ELG-75-12B-3Y LED driver Constant voltage, Constant current 60.0 W 5 A 6 - 12 V DC dimmable, PFC circuit, Surg
Warranty Terms
Warranty Terms 1714192 MEAN WELL ELG-75-12B-3Y LED driver Constant voltage, Constant current 60.0 W 5 A 6 - 12 V DC dimmable, PFC circuit, Surg
Description
The LED power supplies in IP67 Aluminum housing meet the standards EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13, and are thus used for LED lighting applications.
This text is machine translated.
This text is machine translated.
Features
- Metal housing
- Overload protection by circuit breaker (Hiccup), auto recovery
- Protected against short circuit, overload, over voltage
- For LED lighting applications
- 3 in 1 Constant current dimming function via 0 - 10 V/DC, 10 V PWM or external potentiometer
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
- Corresponds to 6 kV surge immunity level IEC61000-4-5.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
