MEAN WELL ELG-75-C1050DA-3Y LED driver Constant current 74.55 W 1050 mA 35 - 71 V DC DALI, Suitable for flammable surfac
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 36.13 / piece)
€ 48.73
-26 %
€ 36.13
plus VAT.
Only 5 Piece(s) available
Highlights & Details
ELG-75-C1050DA-3Y
- Constant current
- 35 - 71 V DC
- 1050 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 180 x 63 x 35.5 mm
- Factory colour
Metal
- Output voltage (max.)
71 V DC
- Output voltage (min.)
35 V DC
- Test mark
CB, MM, UL, ENEC
- Max. output current
1050 mA
- Output current (max.) - rounded
1.05 A
- Operating voltage
230 V AC
115 V AC
- LED driver features
DALI
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
Surge protection
Overvoltage
dimmable
IP67
- Connection
Open end cable
- Max. power
74.55 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
100 V AC
142 V DC
- Weight
800 g
- Power range
74.55 W (max)
- Type
Pulsed
- Width
63 mm
- Height
35.5 mm
- Length
180 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2176641 MEAN WELL ELG-75-C1050DA-3Y LED driver Constant current 74.55 W 1050 mA 35 - 71 V DC DALI, Suitable for flammable surfac
User & Safety Instructions
User & Safety Instructions 2176641 MEAN WELL ELG-75-C1050DA-3Y LED driver Constant current 74.55 W 1050 mA 35 - 71 V DC DALI, Suitable for flammable surfac
Warranty Terms
Warranty Terms 2176641 MEAN WELL ELG-75-C1050DA-3Y LED driver Constant current 74.55 W 1050 mA 35 - 71 V DC DALI, Suitable for flammable surfac
Description
With the ELG series from MEAN WELL, we offer LED power supplies for you, which are characterized by their variety. In addition to the well-known versions CV+CC (constant voltage and constant current) and CC as analogueue dimmable and non-dimmable version, A DA version is also available that can be controlled digitally via the Dali bus. With a set-up time of less than 500ms and a standby consumption of less than 0.5W, the ELG series of power supplies also meet the limit value of the 2009/125/EC Ecodesign Directive, which was tightened in September 2016.
This text is machine translated.
This text is machine translated.
Features
- IP67
- DALI interface
- Protective conductor in the primary cable
- Constant current
- Independant operating device
- Wide range input
- Metal housing
- Overload protection by current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overtemperature
- Built-in PFC circuit
- Suitable for LED lighting applications
- SELV compliant
- corresponds to 6kV Surge Immunity Level
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
