MEAN WELL GD2-241503 DC/DC converter 15 V 5 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Remaining ripple 50 MVP-p
- Capacity load, max. 100 µF
- INSULATION VOLTAGE I/P-O/P 6200 V
- Product type
DC/DC converter
- Type
GD2-241503
- Min. input voltage
10.8 V
- Input voltage (max.)
12 V
- Output voltages
15 V
- Efficiency (max.)
81 %
5 W
- Insulation voltage
6200 V
- Connection
THT
- PSU features
Surge protection
- Operating temperature (min.)
-55 °C
- Operating temperature (max.)
+90 °C
- Dim
(L x W x H) 19.5 x 9.8 x 12.5 mm
- Height
12.5 mm
- Length
19.5 mm
- Width
9.8 mm
- Output voltage (max.)
15 V
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3435591 MEAN WELL GD2-241503 DC/DC converter 15 V 5 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3435591 MEAN WELL GD2-241503 DC/DC converter 15 V 5 W Content 1 pc(s)
Description
The GD2 series is an insulated and unregulated 2W DC-DC converter module with SIP7 package. It has international standard pins, a high degree of efficiency of up to 82%, a wide operating temperature range of 40-+90°C, 6.2KVdc or 4.3KVac I/P-O/P high insulation voltage, short-circuit protection, etc. The models take into account various 12V/15V/24V+ 10% input voltages and a variety of positive and negative output voltages suitable for extremely low leakage currents, industrial controls, telecommunications, motor drivers and solar inverters, distributed power architectures, etc.
