MEAN WELL HDR-100-12 Rail mounted PSU (DIN) Consumption (standby) 0.3 W 12 V DC 7.1 A 85.2 W No. of outputs:1 x Content
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.88
3
4% = € 1.17
€ 25.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.88 / piece)
€ 26.88
plus VAT.
14-day return policy included
Highlights & Details
DIN-Rail Mounting Single Output 1-phase power: 100 W
- Directly on the DIN-rail mountable
- Closed design, touch-proof screw terminals
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Low idle power
- LED display for power-on
- Insulation category II
Technical specifications
- Nominal input voltage
230 V/AC
115 V/AC
- Type
Pulsed
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
85 V AC
- Output voltage
12 V DC
- Input voltage
85-264 V AC
- Input voltage (max.)
264 V AC
- Max. output current
7.1 A
- Output current (max.) - rounded
7.1 A
85.2 W
- Output type (power supply units)
Adjustable
- Phases
1
- Output voltage (nominal)
12 V DC
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 70 x 54.5 x 90 mm
- Weight
270 g
- Output voltage (max.)
13 V DC
- Output voltage (min.)
12 V DC
- Operating temperature (max.)
+70 °C
- Max. operating temperature (derating)
70 °C
- Min. operating temperature (derating)
-30 °C
- Operating temperature (min.)
-30 °C
- Manufacturer part #
HDR-100-12
- Content
1 pc(s)
- MTBF
856500 h
- PSU features
Adjustable voltage output
- Width
54.5 mm
- Height
90 mm
- Length
70 mm
- Max. temperature
+70 °C
- Min. temperature
-30 °C
- Type
HDR-100-12
- Consumption (standby)
0.3 W
- Efficiency
91 %
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1894090 MEAN WELL HDR-100-12 Rail mounted PSU (DIN) Consumption (standby) 0.3 W 12 V DC 7.1 A 85.2 W No. of outputs:1 x Content
User & Safety Instructions
User & Safety Instructions 1894090 MEAN WELL HDR-100-12 Rail mounted PSU (DIN) Consumption (standby) 0.3 W 12 V DC 7.1 A 85.2 W No. of outputs:1 x Content
Conformity certificate
Conformity certificate 1894090 MEAN WELL HDR-100-12 Rail mounted PSU (DIN) Consumption (standby) 0.3 W 12 V DC 7.1 A 85.2 W No. of outputs:1 x Content
Warranty Terms
Warranty Terms 1894090 MEAN WELL HDR-100-12 Rail mounted PSU (DIN) Consumption (standby) 0.3 W 12 V DC 7.1 A 85.2 W No. of outputs:1 x Content
Description
Mean corrugated has its rail power supplies (DIN-rail) of the series HDR the Type HDR-100 with 100 W power. Especially in the building automation and building control, the power supplies with 60 W (HDR-60), which correspond to protection class II The HDR-family of mean corrugated has a step-shaped plastic housing, has an input voltage range of 85 to 264 VAC (also available) and offers 277 VAC models with 5 V, 12 V, 15 V, 24 V and 48 V.
Thanks to the slim design measures the height is only 90 mm, the width 4 SU (70 mm). They can be used on the standardised DIN rail TS-35/7.5 and TS-35/15. To their properties also include a low no-load consumption of< 0,3W, a high degree of efficiency up to 91% and an adjustable DC output voltage as well as a wide operating temperature range (-30 to +70 °C). Also a LED display for operation is available.
The HDR-series of mean corrugated meets the European standard DIN EN 43880, the regulation of the European Union for harmonic current according to EN61000-3-2 class A, as well as all safety regulations according to UL 60950-1, UL508 and EN 61558-2-16.
This text is machine translated.
Thanks to the slim design measures the height is only 90 mm, the width 4 SU (70 mm). They can be used on the standardised DIN rail TS-35/7.5 and TS-35/15. To their properties also include a low no-load consumption of< 0,3W, a high degree of efficiency up to 91% and an adjustable DC output voltage as well as a wide operating temperature range (-30 to +70 °C). Also a LED display for operation is available.
The HDR-series of mean corrugated meets the European standard DIN EN 43880, the regulation of the European Union for harmonic current according to EN61000-3-2 class A, as well as all safety regulations according to UL 60950-1, UL508 and EN 61558-2-16.
This text is machine translated.
Features
- Directly on the DIN-rail mountable
- Closed design, touch-proof screw terminals
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Low idle power
- LED display for power-on
- Insulation category II
